GB/T 32569 Welded Stainless Steel Tube For Seawater Desalination Plants
Product Details
Hot Rolled Welded Steel Tube
,Seawater Desalination Plants Stainless Steel Tube
,GB/T 32569 Stainless Steel Tube
GB/T 32569 Stainless Steel Tube Welded Stainless Steel Tubes For Seawater Desalination Plants
Material, Specification, Key Features
In the realm of stainless steel tubing for seawater desalination plants, GB/T 32569 plays a significant role with its focus on durability, corrosion resistance, and performance efficiency. The material composition and mechanical properties of this welded stainless steel tube ensure its suitability for robust industrial applications.
Chemical Composition
| Element | Composition (%) |
|---|---|
| Carbon | 0.03 max |
| Silicon | 1.0 max |
| Manganese | 2.0 max |
| Phosphorus | 0.04 max |
| Sulfur | 0.03 max |
| Chromium | 16.0-18.0 |
| Nickel | 10.0-14.0 |
| Molybdenum | 2.0-3.0 |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 600 MPa min |
| Yield Strength | 300 MPa min |
| Elongation | 40% min |
| Hardness | HRB 95 max |
Steel Grade
The steel grade conforming to GB/T 32569 standards is characterized by its exceptional sturdiness and corrosion resistance, making it the preferred choice in demanding environments such as seawater desalination plants.
Application
The welded stainless steel tubes manufactured according to the GB/T 32569 specifications find extensive use in seawater desalination plants, where the resistance to corrosion and high performance under challenging conditions are paramount.
Possible Alternative Grades
While GB/T 32569 stands out for its quality and reliability, alternative stainless steel grades like ASTM A249, DIN EN 1.4404, and JIS G3463 can also offer comparable properties for specific applications in seawater desalination plants. Each alternative grade brings its unique blend of characteristics, allowing for flexibility in material selection based on project requirements.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
