12000mm Length Structural Steel Pipe , Gost8733 Gost8734 Carbon Steel Pipes
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
TS16949 , KR , RINA , DNV , GL , PED
Model Number:
Gost8733 Gost8734
Trading Properties
Minimum Order Quantity:
5MT
Price:
USD600-900 per ton
Supply Ability:
6000MT/Month
Product Summary
Structural Steel Pipe , Gost8733 Gost8734 Carbon Steel Pipes Gost8733 Gost8734 Seamless Cold and Warm Deformed pipes Applications: For Structural, liquid transportation, boilers etc Size range: O.D.:6-350m W.T.:1-50mm L:max12000mm Steel Grade Tensile strength, σв, MPa (kgs/mm ) Yield strength, σт, ...
Product Details
Highlight:
structural steel tubing
,structural steel square tubing
Dimension::
6-168mm*1-15mm*12000mm
Application::
For Structural, Liquid Transportation, Boilers Etc
Grade::
10 , 20 , 35 , 45 , 10G2 , 15X , 20X
Section Shape::
Round
Material::
Carbon Steel
Product Name::
Structural Steel Pipe
Product Description
Structural Steel Pipe , Gost8733 Gost8734 Carbon Steel Pipes
Gost8733 Gost8734 Seamless Cold and Warm Deformed pipes
Applications: For Structural, liquid transportation, boilers etc
Size range: O.D.:6-350m W.T.:1-50mm L:max12000mm
| Steel Grade | Tensile strength, σв, MPa (kgs/mm ) | Yield strength, σт, MPa, (kgs/mm ) | Elongation, δs, % | Brinell hardness (provided wall thickness over 10 mm) | |
| Min | Diameter impression mm,min | Hardness number HB,max | |||
| 10(St37.00) | 343(35) | 206(21) | 24 | 5.1 | 137 |
| 20(St44.00) | 412(42) | 245(25) | 21 | 4.8 | 156 |
| 35 | 510(52) | 294(30) | 17 | 4.4 | 187 |
| 45 | 589(60) | 323(33) | 14 | 4.2 | 207 |
| 10G2 | 422(43) | 245(25) | 22 | 4.3 | 197 |
| 15X | 412(42) | - | 19 | 4.5 | 179 |
| 20X | 431(44) | - | 17 | 4.5 | 179 |
| 40X | 618(63) | - | 14 | 4.1 | 217 |
| 30XGCA | 491(50) | - | 18 | 4 | 229 |
| 15XM | 431(44) | 226(23) | 21 | - | - |
Gost8733 Gost8734 Seamless Cold and Warm Deformed pipes
Applications: For Structural, liquid transportation, boilers etc
Size range: O.D.:6-350m W.T.:1-50mm L:max12000mm
| Steel Grade | Tensile strength, σв, MPa (kgs/mm ) | Yield strength, σт, MPa, (kgs/mm ) | Elongation, δs, % | Brinell hardness (provided wall thickness over 10 mm) | |
| Min | Diameter impression mm,min | Hardness number HB,max | |||
| 10(St37.00) | 343(35) | 206(21) | 24 | 5.1 | 137 |
| 20(St44.00) | 412(42) | 245(25) | 21 | 4.8 | 156 |
| 35 | 510(52) | 294(30) | 17 | 4.4 | 187 |
| 45 | 589(60) | 323(33) | 14 | 4.2 | 207 |
| 10G2 | 422(43) | 245(25) | 22 | 4.3 | 197 |
| 15X | 412(42) | - | 19 | 4.5 | 179 |
| 20X | 431(44) | - | 17 | 4.5 | 179 |
| 40X | 618(63) | - | 14 | 4.1 | 217 |
| 30XGCA | 491(50) | - | 18 | 4 | 229 |
| 15XM | 431(44) | 226(23) | 21 | - | - |
