ASTM A312 TP304 TP316 Austenitic Stainless Steel Tube / Pipe For Food Industry

ASTM A312 TP304 TP316 Austenitic Stainless Steel Tube / Pipe For Food Industry

Brand Name: Torich
Model Number: ASTM A312
MOQ: 5MT
Price: negotiable
Payment Terms: L/C, T/T
Supply Ability: 6000MT/Month
Detail Information
Place of Origin:
China
Certification:
GB/T 19001-2008 , ISO 9001:2008 , TS16949
Dimension::
4-35mm*1-50mm
Application::
In The Dairy And Food Industry
Product Name::
Stainless Steel Tube
Section Shape::
Round
Packaging Details:
In bundles or wooden box
Supply Ability:
6000MT/Month
Highlight:

stainless tube steel

,

large diameter stainless steel tube

Product Description

ASTM A312 Seamless and Welded Austenitic Stainless Steel Pipes
Applications:  sanitary tubing in the dairy and food industry, and having special surface finishes




Size range: O.D.: 4.0-305mm     W.T.:1-50mm      L: according to customer requirement

Chemical Requirement:

Grade:                 TPXM19 TPXM10 TPXM11 TPXM29 TP304 TP304L TP304H
UNS S20400 S20910 S20900 S21904 S24000 S30400 S30403 S30409
C, max 0.03 0.060 0.080 0.04 0.08 0.08 0.035  0.040-0.10
Mn, max 7.0-9.0 4.0-6.0 8.0-10.0 8.0-10.0 11.5-14.5 2.00 2.00 2.00
P, max 0.045 0.045 0.045 0.045 0.060 0.045 0.045 0.045
S, max 0.030 0.030 0.030 0.030 0.030 0.030 0.030 0.030
Si, max 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
Cr 15.0-17.0 20.5-23.5 19.0-21.5 19.0-21.5 17.0-19.0 18.0-20.0 18.0-20.0 18.0-20.0
Ni 1.50-3.00 11.5-13.5 5.5-7.5 5.5-7.5 2.3-3.7 8.0-11.0 8.0-13.0 8.0-11.0
Mo 1.50-3.00
Ti
Columbium 0.10-0.30
Tantalum
Nitrogen 0.15-0.30 0.20-0.40 0.15-0.40 0.15-0.40 0.20-0.40
Vanadium 0.10-0.30
Copper
Cerium
Boron
Aluminum
