ASTM A500 Seamless Steel Tube Carbon Steel Structural Tube For High Pressure Boiler
Product Details
Seamless Carbon Steel Structural Pipe
,ASTM A500 Seamless Steel Tube
,High Pressure Boiler Seamless Steel Tube
Seamless Steel Tube Shaped Seamless Carbon Steel Structural Pipe ASTM A500 For High-Pressure Boiler
Seamless carbon steel structural pipes are an essential component of high-pressure boilers, as they help in transporting steam and water throughout the system. ASTM A500 is a widely used standard specification for cold-formed welded and seamless carbon steel structural tubing in round, square, and rectangular shapes.
Material
The material used for ASTM A500 seamless carbon steel structural pipes is carbon steel.
Specification
The specification for ASTM A500 seamless carbon steel structural pipes includes the following requirements:
- Chemical composition
- Mechanical properties
- Dimensional tolerances
- End finish
- Surface finish
Chemical Composition
The chemical composition of ASTM A500 seamless carbon steel structural pipes is as follows:
| Element | Composition, % |
|---|---|
| Carbon | 0.23 max |
| Manganese | 1.35 max |
| Phosphorus | 0.04 max |
| Sulfur | 0.05 max |
| Copper | 0.20 min |
Mechanical Properties
The mechanical properties of ASTM A500 seamless carbon steel structural pipes are as follows:
| Property | Value |
|---|---|
| Tensile strength, min, psi | 58,000 |
| Yield strength, min, psi | 46,000 |
| Elongation in 2 in., min, % | 23 |
| Hardness, HRB | 76 max |
Steel Grade
The steel grade for ASTM A500 seamless carbon steel structural pipes is Grade B.
Application
ASTM A500 seamless carbon steel structural pipes are used in various applications, including high-pressure boilers, mechanical and structural applications, and general fabrication.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
