304 Stainless Steel Hypodermic Tubing Medical Needle Capillary Tube

Basic Properties
Place of Origin: China
Brand Name: Torich
Certification: ISO 9001 TS16949
Model Number: Toich
Tags

stainless tube steel

stainless steel round tube

large diameter stainless steel tube
Product Summary
304 stainless steel hypodermic tubing medical needle tube capillary tube Quick detail: Model Stainless steel tube Standard ASTM A213,ASTM A312,ASTM A789,ASTM A790 Material Grade 201/202/304/316L/S31803/S32750/904L Outer Diameter 0.1mm-600mm Thickness 0.05mm-20mm Length ≤12000mm or as per customer ...

Product Details

Highlight:

Medical Stainless Steel Hypodermic Tubing

,

Medical Needle Capillary Tube

,

304 Stainless Steel Hypodermic Tubing
Certification: ISO
Steel Grade: 300 Series
Application: Chemical
Type: Seamless And Welded
Welding Line Type: TIG
Standard: ASTM
Thickness: 0.4-30mm
Length: 6m Or As Customers' Request
Product Description

304 stainless steel hypodermic tubing medical needle tube capillary tube



Quick detail:

Model
Stainless steel tube
Standard
ASTM A213,ASTM A312,ASTM A789,ASTM A790
Material Grade
201/202/304/316L/S31803/S32750/904L
Outer Diameter
0.1mm-600mm
Thickness
0.05mm-20mm
Length
≤12000mm or as per customer request
Tolerance
1) Outside Diameter: +/-0.02mm
2) Thickness: +/-10% or customer request
3) Length: +/-10mm
Surface
Satin/Hairline: 180#,320#
Polish: 400#,600#,800# or Mirror surface
Pickling
Application
Decoration, (Processed into railings,handrails,doors and Windows),
medical,industry,etc
Packaging
Plastic bag,woven packing,plywood case
(Please send details packing to us if you have other requirements)



Chemical Componet

Grade
C
Si
Mn
P
S
Ni
Cr
Mo
201
≤0.15
≤1.00
0.15.5~7.5
≤0.060
≤0.03
3.50~5.50
16.00~18.00

202
≤0.15
≤1.00
0.7.5~10.00
≤0.060
≤0.03
4.0~6.0
17.00~19.00

301
≤0.15
≤1.00
≤2.00
≤0.045
≤0.03
6.00~8.00
16.00~18.00

302
≤0.15
≤1.00
≤2.00
≤0.045
≤0.03
8.00~10.00
17.00~19.00

304
≤0.07
≤1.00
≤2.00
≤0.045
≤0.03
8.00~10.00
18.00~20.00
-
304L
≤0.030
≤1.00
≤2.00
≤0.045
≤0.03
9.00~13.00
18.00~20.00
-
310S
≤0.08
≤1.00
≤2.00
≤0.045
≤0.03
19.00~22.00
24.00~26.00
-
316
≤0.08
≤1.00
≤2.00
≤0.045
≤0.03
10.00~14.00
16.00~18.00
2.00~3.00
316L
≤0.03
≤1.00
≤2.00
≤0.045
≤0.03
12.00~15.00
16.00~18.00
2.00~3.00
321
≤0.08
≤1.00
≤2.00
≤0.045
≤0.03
9.00~13.00
17.00~19.00
-
430
≤0.12
≤0.75
≤1.00
≤0.040
≤0.03
≤0.60
16.00~18.00
-
430A
≤0.06
≤0.50
≤0.50
≤0.030
≤0.50
≤0.25
14.00~17.00




304 Stainless Steel Hypodermic Tubing Medical Needle Tube Capillary Tube
