Astm A513 1020 Dom Steel Tube In Motorcycle Cylinder
Product Details
astm a513 dom steel tube
,1020 dom steel tube
,motorcycle cylinder dom tubing
ASTM A513 DOM Carbon Steel Tube for Welded 1020 Steel Pipes in Motorcycle Cylinder
1.Introduction:
| Name | ASTM A513 DOM Carbon Steel Tube for Welded 1020 Steel Pipes in Motorcycle Cylinder |
| Type | Carbon |
| Production | Drawn Over Mandral |
| Application | Automotive industry, etc |
| OD | 5-420mm |
| WT | 0.5-25mm |
| Length | 5.8m for 20GP, 11.8 for 40HQ |
| Production | 35-45 days |
| Surafce | Oiled to prevent rust |
| Heat Treatment | according to requirement |
| Package | Packing in seaworthy package, wovan bags or wooden cases |
2.Product details:
(1)Chemical components:
| Material | C | Mn | P MAX | S MAX |
| 1010 | 0.02-0.15 | 0.3-0.6 | 0.035 | 0.035 |
| 1015 | 0.1-0.2 | 0.3-0.6 | 0.035 | 0.035 |
| X 1015 | 0.1-0.2 | 0.6-0.9 | 0.035 | 0.035 |
| 1020 | 0.15-0.25 | 0.3-0.6 | 0.035 | 0.035 |
| X 1020 | 0.15-0.25 | 0.7-1 | 0.035 | 0.035 |
(2)DOM: To produce specialty tubing, this procedure uses a drawbench to pull tubing through and over a mandrel, allowing excellent control of the inside diameter and wall thickness.
(3)Strength:Quality inspection, excellent raw materials, professional equipment, skilled technicians, fast delivery
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples of carbon seamless steel tube ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q:Do you have agent or distributor in our country?
A:We are recruiting area agent and distributor all over the world, welcome to send us your mail or call us for detail discussion.
Q:How is your production capability?
A:1.2000 tons monthly production capacity, 5000 tons monthly trading capability
2.Prompt and Timely shipment
Q:How to get the sample?
A:1.You are requested to pay for sample charges and courier charges from China to your country; and the free sample is according the product like size, steel grade and quantity, please consult our sales for details
2.Sample charges will be refunded when order is placed.
QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking
-
