EN 10305-1 E355 Low Carbon Cold Drawn Cold Rolled Precision Steel Pipe

Basic Information
Place of Origin: China
Brand Name: Torich
Certification: ISO 9001
Model Number: EN 10305-1
Minimum Order Quantity: 5 tons
Price: 1500USD/ton
Packaging Details: In bundles
Delivery Time: 5-8 weeks
Payment Terms: L/C, T/T
Supply Ability: 5000tons per year
Detail Information
Thickness: 0.1mm-60mm Certification: ISO9001-2008
Technique: Cold Drawn Section Shape: Round
Hydraulic Pipe: Hydraulic Pipe Alloy Or Not: NON -alloy
Special Pipe: Thick Wall Pipe Outer Diameter(round): 8 - 100 Mm
Length: Customer's Requirement
High Light:

EN 10305-1 Precision Steel Pipe

,

E355 Low Carbon Precision Steel Pipe

,

E355 Cold Drawn Precision Steel Tube


Product Description

EN 10305-1 E355 Low Carbon Seamless Cold Drawn or Cold Rolled Precision Steel Pipe

high precision metal tubing
high precision steel tubing
ERW/CDW metal tubing
ERW/CDW steel tubing
Hydro metal tubing
Hydro steel tubing

Size range: O.D.:6-420mm W.T.:1-50mm L:max12000mm



Production: Cold Drawn + Cold Rolling



Steel Grade and Chemical Compositions:

Steel Grade C Si Mn P S Al
Steel Name Steel Number max max max max max min
E215 1.0212 0.10 0.05 0.70 0.025 0.025 0.025
E235 1.0308 0.17 0.35 1.20 0.025 0.025 -
E355 1.0580 0.22 0.55 1.60 0.025 0.025 -





Mechanical properties at room temperature
Steel Grade Minimum values for the delivery condition
Steel Name Steel Nubmer (+Cc) (+LCc) (+SR) (+Ad) (+N) NBK
Rm Mpa A % Rm Mpa A % Rm Mpa ReH Mpa A % Rm Mpa A % Rm Mpa ReH Mpa A %
E215 1.0212 430 8 380 12 380 280 16 280 30 290-430 215 30
E235 1.0308 480 6 420 10 420 350 16 315 25 340-480 235 25
E355 1.0580 640 4 580 7 580 450 10 450 22 490-630 355 22



aRm: tensile strength; ReH: upper yield strength; A: elongation after fracture
b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm
d For calclulation purposes the following relation is recommended:ReH≥0.5Rm
e For tubes with outside diameter ≤30mm and wall thickness ≤3mm the ReH minimim values are 10Mpa lower than the values given in this Table
f For tubes with outside diameter>160mm: ReH≥420Mpa



EN 10305-1 E355 Low Carbon Cold Drawn Cold Rolled Precision Steel Pipe 0
