Automobile 5mm OD AISI4130 Moly Alloy Steel Pipe DOM Type

Minimum Order Quantity : 5 tons Price : USD 900-1500/ton
Packaging Details : in anti rust oil protection In hexagonal bundles or cutting to short pices with carton packing. Delivery Time : 30-45 days
Payment Terms : L/C, D/A, T/T, Western Union, MoneyGram, D/P Supply Ability : 30000 tons/year
Place of Origin: Zhejiang,China Brand Name: TORICH
Certification: ISO 9001:2008, ISO14001:2008, TS16949 Model Number: ASTM A513

Detail Information

Product Name: Automobile Steel Tubes AISI4130 Moly Alloy Steel Pipe Keyword: 4130 Steel Tube
Type: ERW+DOM Surface: According To Customer's Request
Material: 1010,1020,1026,4130 Shape: Round
Usage: For Mechinery,mechanical Engineer Length: Max12000mm
OD: 5-420mm WT: 0.5-50mm
High Light:

5mm OD Alloy Steel Pipe

,

AISI4130 Alloy Steel Pipe

,

DOM Alloy Steel Pipe

Product Description

Automobile Steel Tubes AISI4130 Moly Alloy Steel Pipe



Size range

O.D.:6-350mm     W.T.:1-12.5mm      L:max12000mm

Grade

1010, 1020, 1026,4130

 Production

ERW + DOM

Packing
In Hexagonal Bundles, with anti corrosion oil protection, with seaworthy packing

Deliver condition

1. A.W.H.R.    "as welded" from hot-rolled steel
2. A.W.C.R.      "as welded" from cold-rolled steel
3. S.D.C.R.       "sink-drawn", cold-rolled steel
4. M.D.              mandrel drawn
5. S.S.I.D.          special smooth inside diameter

Please specify the delivery condition when sending the enquiry!


Thermal condition:
1. No final thermal treatment
2. Stress relieved
3. Annealed
4. Normalized




                                       Steel Grade and Chemical Compositions:
Steel  Grade C Mn P S Si Cr Mo
max   max max max min
1008 0.10 0.5 0.035 0.035
1010 0.08-0.13 0.30-0.60 0.035 0.035
1018 0.14-0.20 0.30-0.60 0.035 0.035
1020 0.17-0.23 0.30-0.60 0.035 0.035
1026 0.22-0.28 0.60-0.90 0.035 0.035
1035 0.31-0.38 0.60-0.90 0.035 0.035
4130 0.28-0.33 0.40-0.60 0.035 0.035 0.15-0.35 0.80-1.10 0.08-0.25
4140 0.38-0.43 0.75-1.00 0.035 0.035 0.15-0.35 0.80-1.10 0.15-0.25



Steel  Grade Yield Ulitmate             Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    As-Welded Tubing
1008 30     207 42     290 15 50
1010 32     221 45     310 15 55
1020 38     262 52     359 12 62
1026 45     310 62     427 12 68
1035 50     345 66     455 10 75
4130 55     379 72     496 10 80
4140 70     485 90     621 10 85



Steel  Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Sink-Drawn Tubing
1008 38     262 48     331 8 65
1010 40     276 50     345 8 65
1020 50     345 60     414 8 70
1026 55     379 70     483 7 77
1035 70     483 80     552 7 82
4130 50     345 70     483 20 100
4140 65     448 90     621 20 105



Steel  Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Normalizing Tubing
1008 23     159 38     262 30   65
1010 25     172 40     276 30   65
1020 35     207 50     345 25   75
1026 40     276 60     414 25   80
1035 45     310 65     448 20   85



Steel  Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Mandrel-Drawn Tubing
1008 50     345 60     414 5   73
1010 50     345 60     414 5   73
1020 60     414 70     483 5   80
1026 70     483 80     552 5   85
1035 80     552 90     621 5   90
4130 85     586 95     655 5   90
4140 100    690 110     758 5   90



Steel  Grade Yield Ulitmate Elongation RB RB
Strength Strength % min max
  ksi Mpa ksi Mpa
    Mandrel-Drawn Stress-Relieved Tubing
1008 45     310 55     379 12   68
1010 45     310 55     379 12   68
1020 55     379 65    448 10   75
1026 65     448 75    517 10   80
1035 75     517 85    586 10   85
4130 80     552 90     621 10   87
4140 95     655 105     724 10   90



Applications: for Machinery, Mechanical Engineer, Automotive Parts



A513 Automotive Steel Tubes , Carbon and Alloy Steel Mechanical Tubing,4130 steel tube
