SUS304 ASTM A312 TP 316L 600mm Stainless Steel Tube
Product Details
ASTM A312 Stainless Steel Tube
,TP 316L Stainless Steel Tube
,600mm Stainless Steel Tube
06Cr19Ni10,SUS304ASTM A312 TP 316L Seamless Large Diameter 600mm Stainless Steel Pipe ERW Stainless Steel Pipe /SS Tube
Quick detail:
Material:06Cr19Ni10,SUS304,TP316L
Standard:ASTM A312
Size:600mm
Production name:Stainless Steel Pipe ERW Stainless Steel Pipe/SS Tube
Feature:Big Diameter
Material
| Material | |
| Austenitic Stainless Steel | 310S, 309S,316L,321,304L,304 |
| Duplex | S,32750,S32760,S31803,S32205 |
| Nickel-Base Alloy | N08904,N06600,N08825 |
| Copper Nickel Alloy | C70600,C70620 |
| Ferrite | 430,409L |
| Other Special Material | 254SMO,253MA |
| High-Temp Material | 310S,309S,S30815 |
| Titanium Alloys | TA2,TA10,TC4 |
Other material is also available
06Cr19Ni10,SUS304ASTM A312 TP 316L Seamless Large Diameter 600mm Stainless Steel Pipe ERW Stainless Steel Pipe /SS Tube Mainly apply in Electric Power
Oil Refining
Nuclear Power
Drinking Water
Offshore Engineering &Shipbuilding
Natural Gas
Paper making
Construction
Test:
X ray test
Documents:
MTC
X ray test report
Size measuring test report
SGS test report if need third party inspection.
Roting:
Steel Coil---Re-test---Flat Open and Transverse Shear---Shear Longitudinal Shear---Edge Planning and Milling
Butt Welding of plate---Forming(Bending/Reeling)---End Squaring&Tack Welding---Welding Seam Cleaning
Automatic welding---Radiographic Test---Solution Treatment---Rounding---Straightening
End Facing Treatment---Hydrostatic Test--Pickling Passivation--Rinse and Dry---Radiographic Test
Finished Production Testing---Marking---Packing---Finished Product Warehousing--Shipping
Delivery condition:
Heat treatment
Welded
Stainless Steel Pipe ERW Stainless Steel Pipe/SS Tube Standard tolerance:
| Standard | Item | Outside Diameter | Thickness | Roundness
| Straightness | Length | ||
| GB/T 12771 | Heat treatment | High Class | General | |||||
| ＜50 | ±0.20 | ±0.3 | ＞0.5-1.0,±0.15 ＞1.0-2.0 ±0.20 ＞2.0-4.0 ±0.3 ±10% | Not exceed the OD tolerance t/D≤3% ≤1.5%D | OD ≤ 108 mm,≤1.5mm/m ＞ 108-325mm ≤2.0mm/m ＞ 325mm ≤2.5mm/m
| 3000-9000mm, Length tolerance is 0,+20mm
| ||
| ≥40-＜65 | ±0.30 | ±0.40 | ||||||
| ≥65-＜90 | ±0.40 | ±0.50 | ||||||
| ≥90-＜168.3 | ±0.80 | ±1.0 | ||||||
| ＞168.3-＜325 | ±0.75% D | ±1% D | ||||||
| ≥325-＜610 | ±0.6% D | ±1% D | ||||||
| ＞610 | ±0.6% D | ±0.7% or± 10 Chose min value | ||||||
| Welded | All sizes | ±0.5% D or ±0.20 chose the bigger one | ±0.75% D or ±0.30 chose the bigger one | |||||
-
