YB/T 4513 Stainless Steel Tube Food Grade Stainless Steel Welded Pipe For Medical
Product Details:
|
|
Place of Origin: | ZHEJIANG, CHINA |
---|---|
Brand Name: | TORICH |
Certification: | ISO9001, ISO14001, TS16949 |
Model Number: | Grade 304 |
Payment & Shipping Terms:
|
|
Minimum Order Quantity: | 10 Tons |
Packaging Details: | Tubes are packed in bundles or wooden boxes in seaworthy packing. |
Delivery Time: | 20-30 work days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 5000Tons per Year |
Detail Information |
|||
Keyword: | Grade 304 Stainless Steel Industrial Pipe | Material: | 304, 304L, 316, 316L, 410 Etc Stainless Steel |
---|---|---|---|
OD: | 6-914mm | WT: | 0.5-60mm |
Length: | Customers' Requirements | Usage: | Industrial Use |
Delivery Condition: | Annealed And Pickled | Type: | Welded |
High Light: | 914mm stainless steel industrial pipe,914mm stainless 304 industrial pipe,TORICH Stainless Steel Industrial Pipe |
Product Description
TORICH 32 inch Large Diameter Grade 304 Stainless Steel Industrial Pipe
Production process of JCOE large diameter straight seam welded pipe:
Steel Coil→ Re-test→ Flat Open and Transverse Shear→ Shear (Longitudinal Shear)→ Edge Planning and Milling→
Butt Welding of Plate→ Forming (Bending/Reeling)→ End Squaring&Tack Welding→ Welding Seam Cleaning→
Automatic Welding→ Radiographic Test→ Solution Treatment→ Rounding→ Straightening→ End Facing Treatment→
Hydrostatic Test→ Pickling Passivation→ Rinse and Dry→ Radiographic Test→ Finished Product Testing→ Marking→
Packing→ Finished Product Warehousing→ Shipping
Application:
Electric Power, Oil Refining, Nuclear Power, Drinking Water, Offshore Engineering&Shipbuilding, Natural Gas,
Paper Making, Construction
Material Available
Material | Grade |
Austenitic Stainless Steel | 310S, 309S, 316L, 321, 304, 304L |
Duplex | S32750, S32760, S31803, S32205 |
Nickel-Based Alloy | N08904, N06600, N08825 |
Copper Nickel Alloy | C70600, C70620 |
Ferrite | 430, 409L |
Other Special Material | 254SMO, 253MA |
High-Temp Material | 310S, 309S, S30815 |
Titanium Alloys | TA2, TA10, TC4 |
Size
Seam Type | OD | WT |
Single Seam | 6-914mm | 0.5-60mm |
Double Seam | 630-1524mm | 2-80mm |
Circular Seam | over 630mm | 2-100mm |
Density
Grade | ρ (kg/dm³) | Calculation Formula | |
0Cr18Ni9 (06Cr19Ni10) SUS304 TP304 |
00Cr19Ni10 (022Cr19Ni10) SUS304L TP304L |
7.93 7.9 |
W=0.02491 t(D-t) W=0.02482 t(D-t) |
0Cr17Ni12Mo2 SUS316 TP316 |
00Cr17Ni14Mo2 SUS316L TP316L |
8.0 | W=0.02513 t(D-t) |
Product Show:
