Enhanced Condenser ASTM B111 C71500 Alloy Steel Pipe

Name: Enhanced Condenser ASTM B111 C71500 Alloy Steel Pipe
Brand: TORICH INTERNATIONAL LIMITED
SKU: ASTM B111
Price: 1,125.00 USD
Availability: InStock

Brand Name:	Torich
Model Number:	ASTM B111
MOQ:	2 tons
Price:	$1050-1200
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	35 tons /Month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ISO

Name:

Torich C71500 Enhanced Condenser ASTM B111 Seamless Steel Pipe

Standard:

ASTM B111

Grade:

C71500,C71640,C70400,C70600

Application:

Enahnced Condenser

OD:

5-420mm

WT:

0.5-50mm

Length:

Max12000mm

Packaging Details:

Packing in bundles in seaworthyt package

Supply Ability:

35 tons /Month

Highlight:

astm b111 c71500

C71500 Alloy Steel Pipe

ASTM B111 Alloy Steel Pipe

Product Description

Torich C71500 Enhanced Condenser ASTM B111 Seamless Steel Pipe

Standard Specification for Copper and Copper -Alloy Seamless Condenser Tubes and Ferrule Stock

Referenced Standards:

B153 Test method for expansion of copper and copper alloy pipe and tubing

B154 Test method for mercurous nitrate test for copper alloys

B170 Specification for oxygen-free electrolytic copper refinery shapes

B224 Classification of coppers

B846 Terminology for copper and copper alloys

B856 Test method for ammonia vapor test for determining susceptibility to stress corrosion cracking in copper alloys

Key words: Condenser tube, copper, copper alloys, evaporator, ferrule stock, heat exchanger,seamless tube,UNS No. C10100, UNS No. C10200, UNS No. C10300,UNS No. C10800,UNS No. C12000,UNS No. C12200,UNS No. C14200,UNS No. C19200,UNS No. C23000,UNS No. C28000,UNS No. C44300, UNS No. C44400,UNS No. C44500,UNS No. C60800

Chemical Composition

Steel Grade	Cu	Sn	Al	As	Ni	Fe	Mn	Pb	Zn
C70400	Remain	-	-	-	4.8-6.2	1.3-1.7	0.3-0.8	0.05 max	1.0 max
C70600	Remain	-	-	-	9.0-11.0	1.0-1.8	1.0 max	0.05 max	1.0 max
C71500	Remain	-	-	-	29.0-33.0	0.4-1.0	1.0 max	0.05 max	1.0 max
C71640	Remain	-	-	-	29.0-32.0	1.7-2.3	1.5-2.5	0.05 max	1.0 ma

Mechanical Properties

Steel Grade	Temper	Tensile Strength Mpa	Yeild Strength Mpa		Elongation %	Expansion Requirement %	Grain Size mm
Steel Grade	Temper	Min	Min	Max	Min	Min	Min	Max
C70400	061	260	85	-	-	30	0.01	0.045
C70400	H55	275	205	-	-	20	-	-
C70600	061	275	105	-	-	30	0.01	0.045
C70600	H55	310	240	-	-	20	-	-
C71500	061	360	125	-	-	30	0.01	0.045
	HR50A	495	345	-	12	20	-	-
	HR50B	495	345	-	15	20	-	-
C71640	061	435	170	-	-	30	0.01	0.045
C71640	HR50	560	400	-	-	20	-	-

Show:

QUALITY CONTROL:

1.Incoming Raw Material Inspection

2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking

100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
