OD3.18mm N06022 Hastelloy Tube For Chlorination System

Product Description

Hastelloy N06022 Tubes

Quick detail:

OD:3.18-114.3mm

592. :0.5-12mm

Hastelloy C-22 (N06022)

Hastelloy C-22 (UNS N06022/W N 2.4602)Hastelloy alloy

Chemical compostion

Ni Cr C Si Mn Mo W V Co Fe

remain 14.5-16.5 ≤0.02 ≤0.08 ≤1.0 15-17 3-4.5 ≤0.35 ≤2.5 4.0-7.0

Mechanical properties

Temperature ℃ σ0.2MPa σbMPa δ5%

Room ≥285 ≥690 ≥40

Production method: Cold rolled or cold drawing

Size OD:6-300mm ID:4-250mm

• : GB,ASTM,AMSE

Hastelloy C-22 other applications:

1. Acetic acid/acetic anhydride

2.Acid dip

3. Cellophane manufacture

4. Chlorination system

5. Complex acid mixture

6.Roll in electric galvanizing bath

7. Expansion bellows

8. Flue gas cleaner system

9.Geothermal well

10. Hydrogen fluoride furnace cleaner

11. Incinerator cleaner system

12.Nuclear fuel regeneration

13. Pesticide production

14. Phosphoric acid production

15. Pickling system

16.Plate heat exchanger

17. Selective filtration system

Hastelloy G-35 (N06035)
