UNS N04400 ASTM B165 Nickel Copper Tubing
Basic Properties
Place of Origin:
Zhejiang China
Brand Name:
TORICH
Certification:
ISO 9001
Model Number:
ASTM B165
Trading Properties
Minimum Order Quantity:
100 Kg
Price:
Negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
250 Tons Per Month
Product Summary
ASTM B165 Nickel-Copper Alloy UNS N04400 Seamless Tube Mechanical Properties of Small-Diameter and Light-Wall Tubing Condition Tensile Strength(Mpa) Yield Strength min Mpa Elongation in 2in or 50mm min% Annealed 585max 195 32 Half-hard 585min 380 12 Full hard 760min 620 3 Chemical Requirements ...
Product Details
Highlight:
ASTM B165 Nickel Copper Tubing
,UNS N04400 Nickel Copper Tubing
,UNS N04400 Heat exchanger Tubing
Application:
Boiler, Heat Exchanger
Surface:
Bright Annealed & Polished
Color:
Nickel Nature, Silver Gary
Technique:
Cold Rolled Hot Rolled
Product Description
ASTM B165 Nickel-Copper Alloy UNS N04400 Seamless Tube
Mechanical Properties of Small-Diameter and Light-Wall Tubing
| Condition | Tensile Strength(Mpa) | Yield Strength min Mpa | Elongation in 2in or 50mm min% |
| Annealed | 585max | 195 | 32 |
| Half-hard | 585min | 380 | 12 |
| Full hard | 760min | 620 | 3 |
Chemical Requirements
|
Element |
Composition Limit % | Product(check)Analysis Variations ,under min or over max , of the specified Limit of Element |
| Ni | 63min | 0.45 |
| Cu | 38min 34max | 0.15 0.20 |
| Fe | 2.5max | 0.05 |
| Mn | 2.0max | 0.04 |
| C | 0.3max | 0.02 |
| Si | 0.5max | 0.03 |
| S | 0.024max | 0.005 |
Delivery Conditions :
1. Annealed - Soft,with a dull matte finish
2. Stress Relieved - Thermally treated below the annealing tempreature to relieve the major
portion of the internal stress, with a thin , light to medium-dark surface
ASTM B407
Reference Standard:
B829 Specification for general requirements for Nickel and Nickel Alloy seamless pipe and tube.
E140 Hardness conversation tables for material relationship among brinell hardness, vickers hardness,
rockwell hardness, superficial hardness, knoop hardness, scleroscope hardness, and leeb hardness.
