Corrosion Resistance ISO 9001 Monel 400 Nickel Alloy Pipe

Basic Properties
Place of Origin: Zhejiang China
Brand Name: TORICH
Certification: ISO 9001
Model Number: Monel 400
Trading Properties
Minimum Order Quantity: 0.5 Ton
Price: USD 4000 Per Ton
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Tons Per Month
Tags

heat exchanger tubes

Welded Stainless Steel Pipe

nickel alloy pipe
Product Summary
Corrosion Resistance ISO 9001 Monel 400 Nickel Alloy Pipe Different Standard Monel 400 UNS N04400 DIN W. Nr. 2.4360, 2.4361 Chemical composition: Ni: 63.0 MIN Cu: 28.0-34.0 Fe: 2.50 MAX C: 0.30 MAX Mn: 2.00 MAX S: 0.024 MAX Si: 0.50MAX Physical properties: Density: 8.80g/cm3 Melting range: 1300-1350...

Product Details

Highlight:

Corrosion Resistance Nickel Alloy Pipe

,

ISO 9001 Approved Nickel Alloy Pipe

,

Monel 400 Nickel Alloy Pipe
Ni (Min): 63.0%
Powder Or Not: Not Powder
Grade: N04400/2.4360/2.4361/M35-1
Ultimate Strength (≥ MPa): 480
Elongation (≥ %): 35
Density: 8.83 G/cm3
Product Description

Corrosion Resistance ISO 9001 Monel 400 Nickel Alloy Pipe



Different Standard

Monel 400

UNS N04400

DIN W. Nr. 2.4360, 2.4361



Chemical composition:

Ni: 63.0 MIN Cu: 28.0-34.0 Fe: 2.50 MAX C: 0.30 MAX Mn: 2.00 MAX

S: 0.024 MAX Si: 0.50MAX



Physical properties:

Density: 8.80g/cm3 Melting range: 1300-1350℃



Metallographic structure of Monel 400:

The structure of Monel400 alloy is a high - strength single - phase solid solution.



Corrosion resistance of Monel 400:

Monel400 alloy has excellent corrosion resistance in fluorine gas, hydrochloric acid,

sulfuric acid, hydrofluoric acid and their derivatives.At the same time,

it has better corrosion resistance than copper base alloy in seawater.



Acid medium:

Monel400 is resistant to corrosion in less than 85% sulfuric acid.

Monel400 is one of the few important materials that can withstand hydrofluoric acid.



Ammonia corrosion:

Monel400 alloy has high nickel content, so it can withstand the corrosion under anhydrous ammonia and ammoniation conditions below 585℃.



Tolerance
a) Outer Diameter: + - 0.1mm
b) Wall Thickness: + - 0.02mm
c) Length: + - 5mm
Standard
AISI, ASTM, DIN, EN, GB and JIS
ASTM A276, A484, A564, A581, A582, EN 10272, JIS4303, JIS G 431, JIS G 4311 and JIS G 4318
Material
200 series: 201,202,202Cu,204Cu,
300 series: 301,303Cu,304L H,304Cu,305,309S,310S,316L H Ti,321 H,347H,330,
400 series: 409L,410,416F,420F,430,431,440C,441,444,446,
600 series: 13-8ph,15-5ph,17-4ph,17-7ph(630,631),660A B C D,
Duplex: 2205(UNS S31803 S32205),2507(UNS S32750),UNS S32760,2304,LDX2101,LDX2404,LDX4404,904L

Alloy : Alloy 20,Alloy 28,Alloy 31
Hastelloy: Hastelloy B B-2,Hastelloy B-3,Hatelloy C22,Hastelloy C-4,Hastelloy S,
Hastelloy C276,Hastelloy C-2000,Hastelloy G-35,Hastelloy G-30,Hastelloy X, Hastelloy N
Haynes: Haynes 230,Haynes 556,Haynes 188
Inconel: Inconel 600,Inconel 601,Inconel 602CA,Inconel 617,Inconel 625,Inconel 718,Inconel X-750,Carpenter 20
Incoloy: Incoloy 800 800H 800HT,Incoloy 825,Incoloy 925,Incoloy 926
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400,Monel K500
Nitronic: Nitronic 40,Nitronic 50,Nitronic 60
Nimonic: Nimonic 75,Nimonic 80A,Nimonic 90

Others: 254SMo,253Ma,F15,Invar36,1J22,N4,N6 etc
1.4057,1.4313,1.4362,1.4372,1.4378,1.4418,1.4482,1.4597,1.4615,1.4662,1.4669,
1.4913,1.4923 etc

Main market
We have frequenter customers from
Europe: Germany,Netherland,Russia, Finland,Czech,Ukraine,Italy,Spain,Poland
Middle East:Iran,UAE,SA,Iraq,Qatar,Isreal,Jordan,Bahrain,Kuwait
South America:Brazil,Chile,Peru,Venezuela,Uruguay,Argentina
Africa:Egypt,South Africa,Nigeria
Central&North America:Mexico,US,Canada,Costa Rica
South East Asia and Pacific:Japan,South Korea,Singapore,Thailand,Indonesia,Australia
Length
1m-6m or subject to the clients request
Surface
180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or
800G Mirror finish and so on.
Package
Seaworthy packing or as the customers requirement
Application
Alloy steel tubes usually applied in motor,construction, oil, medicine, food, paper, machi
nery, washingmachine,chemicals, food containers and other industries. seawater environment, petrochemical,
fertilizer, oil refining, oil and natural gas, light/food, paper pulp and making paper, energy and
environmental-protection industry.
Delivery Time
5-30days, subject to the quantity and customers requirement
Note
We can produce other standard as the customers requirement



Corrosion Resistance ISO 9001 Monel 400 Nickel Alloy Pipe 0



Corrosion Resistance ISO 9001 Monel 400 Nickel Alloy Pipe 1



Corrosion Resistance ISO 9001 Monel 400 Nickel Alloy Pipe 2















Mr. Richard SHEN

Managing Director
