ASTM B167 Inconel600 601 625 UNS No6601 No6625 No6600 Nickel Alloy Seamless Pipe

Basic Properties
Place of Origin: Zhejiang China
Brand Name: TORICH
Certification: ISO 9001
Model Number: NO6601 NO6625 NO6600
Trading Properties
Minimum Order Quantity: 0.5 Ton
Price: USD 3500-5000 Per Ton
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Tons Per Month
Tags

heat exchanger tubes

Welded Stainless Steel Pipe

nickel alloy pipe
Product Summary
INCONEL600 INCONEL601 INCONEL625 UNS NO6601 NO6625 NO6600 NICKEL ALLOY SEAMLESS PIPE /TUBE Inconel is a family of austenitic nickel-chromium-based super alloys. Inconel alloys are oxidation-corrosion-resistance materials well suited for service in extreme environments subjected to pressure and heat...

Product Details

Highlight:

Inconel 601 Nickel Alloy Seamless Pipe

,

No6625 Nickel Alloy Seamless Pipe

,

No6600 Nickel Alloy Seamless Pipe
Ni (Min): 72%
Resistance (ΜΩ.M): 1.5
Ultimate Strength (≥ MPa): 1267
Density: 8.43g/cm3
Product Description

INCONEL600 INCONEL601 INCONEL625 UNS NO6601 NO6625 NO6600 NICKEL ALLOY SEAMLESS PIPE /TUBE



Inconel is a family of austenitic nickel-chromium-based super alloys.

Inconel alloys are oxidation-corrosion-resistance materials well suited for service in extreme environments subjected to pressure and heat.When heated,Inconel forms a thick,stable,passivating oxide layer protecting the surface from further attack.Inconel retains strength over a wide temperature range,attractive for high temperature applications where aluminum and steel would succumb to creep as a result of thermally induced crystal vacancies,Inconel's high temperature strength is developed by solid solution strengthening or precipitation hardening,depending on the alloy.


Size dimension range:

Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

Inconel Chemical Composition
Item
600
601
617
625
690
718
X750
825
C
≤0.15
≤0.1
0.05-0.15
≤0.08
≤0.05
≤0.08
≤0.08
≤0.05
Mn
≤1
≤1.5
≤0.5
≤0.35
≤0.5
≤0.35
≤1
≤1
Fe
6-10
rest
≤3
rest
7-11
rest
5-9
≥22
P
≤0.015
≤0.02
≤0.015
--
--
--
--
--
S
≤0.015
≤0.015
≤0.015
≤0.015
≤0.015
≤0.01
≤0.01
≤0.03
Si
≤0.5
≤0.5
≤0.5
≤0.35
≤0.5
≤0.35
≤0.5
≤0.5
Cu
≤0.5
≤1
--
≤0.3
≤0.5
≤0.3
≤0.5
1.5-3
Ni
≥72
58-63
≥44.5
50-55
≥58
50-55
≥70
38-46
Co
--
--
10-15
≤10
--
≤1
≤1
--
Al
--
1-1.7
0.8-1.5
≤0.8
--
0.2-0.8
0.4-1
≤0.2
Ti
--
--
≤0.6
≤1.15
--
--
2.25-2.75
0.6-1.2
Cr
14-17
21-25
20-24
17-21
27-31
17-21
14-17
19.5-23.5
Nb+Ta
--
--
--
4.75-5.5
--
4.75-5.5
0.7-1.2
--
Mo
--
--
8-10
2.8-3.3
--
2.8-3.3
--
2.5-3.5
B
--
--
≤0.006
--
--
--
--
--





Other Products Series


FeCrAl Alloy: OCr15Al5,1Cr13Al4, 0Cr21Al4, 0Cr21Al6, 0Cr25Al5, 0Cr21Al6Nb,0Cr27Al7Mo2.
NiCr Alloy: Cr20Ni80,Cr30Ni70,Cr20Ni35,Cr20Ni30,Cr15Ni60.
CuNi Alloy: NC003,NC010,NC012,NC015,NC020,NC025,NC030,NC040,NC050,Constantan,6J8/11/12/13/.
Welding wire: ERNiCrMo-3/4/13,ERNiCrFe-3/7,ERNiCr-3/7,ERNiCu-7,ERNi-1, ER70S-6.
Thermocouple alloy: K,J,E,T,N, S,R,B,KX,JX,EX,TX,NX.
Inconel alloy: Inconel 600,601,617,X-750,625,690,718,825.
Incoloy alloy: Incoloy 800,800H,800HT,825,925.
Hastelloy alloy: HC-276,C-22,C-4,HB,B/2/3,X,N.
Monel Alloy: Monel 400,K500.
High-temperature alloy : A-286,Nimonic80A,Nimonic 90,GH1140,GH3625,GH3536,GH4169
Thermal spray alloy: Inconel 625,Ni95Al5,Monel400,45CT,HC-276,K500,Cr20Ni80.



ASTM B167 Inconel600 601 625 UNS No6601 No6625 No6600 Nickel Alloy Seamless Pipe 0



ASTM B167 Inconel600 601 625 UNS No6601 No6625 No6600 Nickel Alloy Seamless Pipe 1



ASTM B167 Inconel600 601 625 UNS No6601 No6625 No6600 Nickel Alloy Seamless Pipe 2





ASTM B167

Referenced ASTM Standard:
B829 Specification for general requirements for Nickel and Nickel alloy seamless pipe and tube
B880 Specification for general requirements for Chemical check analysis limits for Nickel, Nickel alloys and Cobalt alloys.
E8 Test method for tension testing of metallic materials.
E29 Practice for using significant digits in test data to determine conformance with sprcifications.
E38 Methods for Chemical Analysis of Nickel-Chromium and Nickel-Chromium-Iron Alloy.
E112 Test Methods for determining the average grain size.
E527 Practice for numbering metals and alloys in the unified numbering system (UNS)
E1473 Test methods for chemical analysis of Nickel, Cobalt and high-temperature alloys.

Keywords: seamless pipe; seamless tube; UNS N06025; UNS N06045; UNS N06600; UNS N06601; UNS N06603; UNS N06617; UNS N06674; UNS N06690; UNS N06693; UNS N06696
