Bright Alloy Tubing Inconel 718 Round Tubes
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO 9001
Model Number:
Inconel 718
Trading Properties
Minimum Order Quantity:
1 Tons
Price:
USD 800-1200/Ton
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
250 Tons Per Month
Product Summary
Bright Alloy Tubing Inconel 718 Round Tubes Product Description Inconel 718 alloy is a precipitation hardened nickel-ferrochrome alloy containing niobium and molybdenum, which has high strength, good toughness and corrosion resistance in high and low temperature environments when the temperature is ...
Product Details
Highlight:
Inconel 718 Round Tubes
,Bright Alloy Round Tubes
Product Name:
Bright Alloy Tubing Inconel 718 Round Tubes
Key Word:
Inconel 718
Grade:
Nickel Base Alloy
Elongation (≥ %):
12
Ultimate Strength (≥ Mpa):
1275
Surface:
Bright
Product Description
Bright Alloy Tubing Inconel 718 Round Tubes
Product Description
Inconel 718 alloy is a precipitation hardened nickel-ferrochrome alloy containing niobium and molybdenum, which has high strength, good toughness and corrosion resistance in high and low temperature environments when the temperature is below 650℃. The state may be solid solution treatment or precipitation hardening state.
Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Product Show
