ASTM A789 Super Duplex 2507 Pipe Cold Drawn Stainless Steel Tube For Petrochemical
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
Minimum Order Quantity : | 2 Tons | Price : | negotiable |
---|---|---|---|
Packaging Details : | Tubes are packed in wooden boxes or hexagonal bundles in seaworthy packing. | Delivery Time : | 30 - 45 days |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 5000 Tons per Year |
Place of Origin: | CHINA | Brand Name: | Torich |
---|---|---|---|
Model Number: | ASTM A268 |
Detail Information |
|||
Certification: | ISO | Product Name: | Ferritic Seamless And Welded Tubing ASTM A268 TP410 Stainless Steel Tube |
---|---|---|---|
Standard: | ASTM | Type: | Seamless And Welded |
Steel Grade: | TP405,TP410,TP409,TP410S,TP430,etc. | Shape: | Round |
Surface: | Oiled | Finish: | Plain |
Product Description
Product Description
Standard |
ASTM A268 |
Material |
TP405, TP410, TP430, TP446-1, TP446-2, 26-3-3, other material is also available |
O.D. | 3.2 - 200 mm |
W.T. | 0.5 - 30 mm |
Length | Max 12000 mm |
Chemical Composition
Grade
|
UNS
|
C
|
Mn
|
P
|
S
|
Ni
|
Cr
|
Mo
|
N
|
TP410
|
S41000
|
0.15 max
|
1.00 max
|
0.040 max
|
0.030 max
|
---
|
11.5-13.5
|
---
|
---
|
|
S42035
|
0.08 max
|
1.00 max
|
0.045 max
|
0.030 max
|
1.0-2.5
|
13.5-15.5
|
---
|
0.30-0.50
|
TP430
|
S43000
|
0.12 max
|
1.00 max
|
0.040 max
|
0.030 max
|
---
|
16.0-18.0
|
---
|
---
|
TP446-1
|
S44600
|
0.025 max
|
1.50 max
|
0.040 max
|
0.030 max
|
≤0.75
|
23-27
|
---
|
0.025 max
|
TP446-2
|
S44600
|
0.012 max
|
1.50 max
|
0.040 max
|
0.030 max
|
≤0.50
|
23-27
|
---
|
0.025 max
|
26-3-3
|
S44660
|
0.030 max
|
1.50 max
|
0.040 max
|
0.030 max
|
1.0-3.5
|
25-28
|
---
|
0.040 max
|
Tensile and hardness requirements
Grade
|
UNS
|
Tensile Strength, min ksi MPa
|
Yeild Strength, min ksi MPa
|
Elongation in 2 in or 50mm, min %
|
Rockwell Hardness B Scale
|
TP410
|
S41000
|
60 (415)
|
30 (205)
|
20
|
95
|
|
S42035
|
80 (550)
|
55 (380)
|
16
|
88
|
TP430
|
S43000
|
60 (415)
|
35 (240)
|
20
|
90
|
TP446-1
|
S44600
|
70 (485)
|
40 (275)
|
18
|
95
|
TP446-2
|
S44600
|
65 (450)
|
40 (275)
|
20
|
95
|
26-3-3
|
S44660
|
85 (585)
|
65 (450)
|
20
|
25
|
Characteristic:
Good concentricity
Good surface quality
Good OD and ID tolerance
High Precision
Stable quality
Smooth
Delivery & Packaging
FAQ
A: A professional steel pipes materials inventor, manufacturer and solution provider
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us.
