Incoloy 800 Incoloy 800h Incoloy 825 Tubing Inconel Pipe
Product Details
Incoloy 800h Tubing
,Incoloy 825 Tubing
,Inconel Pipe Tubing
Incoloy 800 Incoloy 800h Incoloy 825 Tubing Inconel Pipe
Incoloy 800 has good rupture and creep strength and excellent resistance to oxidation,
carburization and sulfidation attemperatures up to 816℃.
It also resists general corrosion by many aqueous media.
For Applications requiring higher stress rupture and creep properties,
especially at temperatures above 816℃, Incoloy 800H and 800HT are recommended.
Incoloy 800 is readilyformed, welded and machined.
Basic Information
Outer Diameter : 3.18mm-101.60mm
Wall Thickness : 0.50mm-20.00mm
Length :Normally fixed length 6m, can as per customer’s requirement
Standard : ASTM B163; ASTM B167; ASTM B444; ASTM B622 ect
Material Grade :
Alloy 800 / 800H / 800HT, Alloy 625/UNS N06625,
Alloy 600/UNS N06600, Alloy601/UNS N06601,
Alloy 800/UNS N08800, Alloy 825/UNS
N08825, Alloy400/UNS N04400; etc
Application
Chemical and petrochemical process piping
heat exchangers
furnace components
carburizing equipment,
heating-element sheathing
and nuclear power steam-generator tubing
Delivery Time
30 working days after received your deposit (Normally according to the order quantity)
Test
NTD(Ultrasonic test, Eddy Current test)
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test)
Metal Test(Metallographic Analysis, Impact Test-High/low temperature)
Chemical Analysis(Photoelectric Emission Spectroscopic)
-
