Heat Exchangers OD 420mm ASTM A178 ERW Welded Steel Tube
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO9001 ISO14001
Model Number:
ASTMA178
Trading Properties
Minimum Order Quantity:
5 tons
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Summary
ASTM A178 ERW Welded Carbon Steel Boiler and Super Heater Tubes Applications: for Boilers,Superheaters, Heat-Exchangers, Condensers, Boiler flues, superheater flues and e ends Production: Electric Resistance Welding Size range: O.D.:6-127mm W.T.:0.9-9.1mm L: according to customer requirement STEEL ...
Product Details
Highlight:
ERW Welded Steel Tube
,ASTM A178 Welded Steel Tube
,OD 420mm Welded Steel Pipe
Product Name:
ASTM A178 ERW Welded Carbon Steel Boiler And Super Heater Tubes
Key Word:
Boiler Steel Tube
Technique:
ERW
Thickness:
0.5 - 50 Mm
Outer Diameter:
5 - 420 Mm
Section Shape:
Round
Surface Treatment:
Oil
Alloy Or Not:
Non-alloy
Product Description
ASTM A178 ERW Welded Carbon Steel Boiler and Super Heater Tubes
Applications: for Boilers,Superheaters, Heat-Exchangers, Condensers, Boiler flues, superheater flues and e ends
Production: Electric Resistance Welding
Size range: O.D.:6-127mm W.T.:0.9-9.1mm L: according to customer requirement
STEEL GRADE AND CHEMICAL COMPOSITIONS
| Element | Grade A | Grade C | Grade D |
| C | 0.06 - 0.18 | ≤ 0.35 | ≤ 0.27 |
| Mn | 0.27 - 0.63 | ≤0.80 | 1.00 - 1.50 |
| P | ≤ 0.035 | ≤ 0.035 | ≤ 0.030 |
| S | ≤ 0.035 | ≤ 0.035 | ≤ 0.015 |
| Si | ... | ... | ≥ 0.10 |
| Mechanical Properties | Grade A | Grade C | Grade D |
| Tensil Strength: min ksi[Mpa] | 47[325] | 47[415] | 70[485] |
| Yield Point: min ksi[Mpa] | 26[180] | 37[255] | 40[275] |
| Elongation: | ≥35% | ≥30% | ≥30% |
Competitive Advantage:
100% good quality and price
The best service in steel field.. Including after-sales service
Reasonable price. We only illing to do business with sincere buyers.
We could produce this pipe according American standard.
We are also a manufacturer,so we can provide the products in conformity with your requirements
rapidly Our company has rich technical force and advanced production equipment and coordinated
advanced test equipment and method.
ASTM A178 ERW Welded Carbon Steel Boiler and Super Heater Tubes
