Name: Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe
Brand: TORICH INTERNATIONAL LIMITED
SKU: ASTM B861 ASME SB861
Price: 25,002.00 USD
Availability: InStock

Home > products > Alloy Steel Pipe >

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe

alloy steel tube

alloy steel seamless tube

Place of Origin:

ZHEJIANG, CHINA

Brand Name:

TORICH

Certification:

ISO9001, ISO14001, TS16949

Model Number:

ASTM B861 ASME SB861

Request A Quote

Product Details

Product Name:

Seamless Titanium Tubes Pipes For Bicycle Frame

Keyword:

Titanium Pipes

Standard:

ASTM B861 ASME SB861

Processing:

Drawing/Extruded

Material:

Gr1, Gr2, Gr7, Gr9, TA1, TA2, TA9 Etc

Shape:

Round Shape

Length:

15m Max

OD:

3-210mm

WT:

0.2-6mm

Usage:

Bicycle Frame

Highlight:

alloy steel tube

alloy steel seamless tube

Payment & Shipping Terms

Minimum Order Quantity

1 Tons

Price

negotiable

Packaging Details

Titanium Pipes packed in wooden boxes or hexagonal bundles in seaworthy packing.

Delivery Time

30-45 work days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

50000Tons per Year

Min Mpa Extruded Titanium Alloy Steel Pipe , Hot Rolled Steel TubingTA1 240

Get Best Price

video

Seamless Alloy Steel Tubing , Hot Rolled Steel Pipe 4140 / 4130 / 4140 / 42CrMo

Get Best Price

video

SCH10 ASTM B407 Nickel Iron Chromium Alloy Steel Pipe

Get Best Price

video

UNS N08825 ASTM B163 Standard Nickel Alloy Steel Pipe

Get Best Price

86-574-88086983

Contact Now

Product Description

TORICH ASTM B861 ASME SB861 Seamless Titanium Tubes Pipes for Bicycle Frame

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 0

Material : Titanimu Alloy Steel,

Characteristic of the material:High strength ,low density,good mechanical property ,good tenacity.good corrosion resistance . titanium alloy steel seamless pipe

It can be made by seamless and welded.and widely apply in power generation,Aerospace,oil and gas ,chemical processing.

Available size list:

OD 6-127mm

WT: 0.5-10mm

Cold drawn Seamless pipes with Ti and Ti alloy

grade	condition	Diameter/mm	Wall thickness /mm
grade	condition	Diameter/mm	0.5	0.6	0.8	1	1.25	1.5	2	2.5	3	3.5	4	4.5
TA1,TA2,TA3,TA9,TA9-1, TA10	Annealing (M)	>10-15	o	o	o	o	o	o	o	-	-	-	-	-
		>15-20	-	o	o	o	o	o	o	o	-	-	-	-
		>20-30	-	o	o	o	o	o	o	o	-	-	-	-
		>30-40	-	-	-	-	o	o	o	o	o	-	-	-
		>40-50	-	-	-	-	o	o	o	o	o	o	-	-
		>50-60	-	-	-	-	-	o	o	o	o	o	o	-
		>60-80	-	-	-	-	-	-	o	o	o	o	o	o

Welded pipes

grade	condition	Diameter/mm	Wall thickness /mm
grade	condition	Diameter/mm	0.5	0.6	0.8	1	1.25	1.5	2
TA1,TA2,TA3,TA9,TA9-1, TA10	Annealing (M)	6-10	o	o	o	o	o	o
		>10-15	o	o	o	o	o	o
		>15-30	o	o	o	o	o	o	o

Tolerance detail:

Torerance for OD and WT
OD	Tolerance	WT Tolerance
6-25	±0.10	±10%
>25-38	±0.13
>38-50	±0.15
>50-60	±0.18
>60-80	±0.25

Seamless and welded rolled pipe length
Type	Seamless			Welded rolled pipe
	OD≤15	OD>15		WT
		WT≤2.0	WT>2.0-4.5	0.5-0.8	>0.8-2.0
Length	500-4000	500-9000	500-6000	500-8000	500-5000
Note: Other lengths are also available.

Welded Pipe length
Type	Welded pipe
	WT0.5-1.25	WT>1.25-2.0	WT>2.0-2.5
Length	500-15000	500-6000	500-4000
Note: Other lengths are also available.

Mechanical porperty :

Mechanical porperty at room temperature
Alloy grade	Condition	Mechanical porperty at room temperature
Alloy grade	Condition	Tensile strength /Mpa	specified non-proportional extension strength /Mpa	percentage elongation after fracture %
TA1	Annealing	≥240	140-310	≥24
TA2		≥400	275-450	≥20
TA3		≥500	380-550	≥18
TA9		≥400	275-450	≥20
TA9-1		≥240	140-310	≥24
TA10		≥460	≥300	≥18

Grade	Tube diameter expanding rate /% min
TA1,TA9-1	22
TA2,TA9	20
TA3,TA10	17

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 1

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 2

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 3

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 4

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 6

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 7

Bicycle Frame ASTM B861 ASME SB861 Alloy Steel Pipe 8

Q: Are you trading company or manufacturer ?

A: A professional steel pipes materials inventor, manufacturer and solution provider

Q: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, and it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but you need to pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
If you have another question, pls feel free to contact us
