ASTM A249 304 316 Stainless Steel Tube Welded Coiled Heat Exchanger Tube

ASTM A249 304 316 Stainless Steel Tube Welded Coiled Heat Exchanger Tube

Brand Name: TORICH
Model Number: ASTM A249 304 316
MOQ: 1 ton
Price: negotiable
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 60000ton/year
Detail Information
Place of Origin:
CHINA
Certification:
ISO9001, TS16949
Product Name:
Stainless Tube Coil
Standard:
ASTM A249
Technique:
Welded
Section Shape:
Round
Certification:
ISO9001, TS16949
Alloy Or Not:
Stainless
Secondary Or Not:
Non-secondary
Surface:
Polished
Shipment:
Ocean/ Air
Packing:
In Coils, In Wooden Boxes
Packaging Details:
In coils, in wooden boxes
Supply Ability:
60000ton/year
Highlight:

stainless steel round tube

,

stainless tube steel

Product Description

ASTM A249 304 316 Welded Stainless Steel Capillary Coiled Tubing Beer Tube Coil



OD:6-127mm
WT:0.5-12mm

Grade: 304 316 317 etc



Seamless stainless Steel pipe coil Coiled heat exchanger Tube SUS304 / 304L / 316L

Mechanical Properties:



Material Mechanical Properties
Tensile Strength ≥ MPa yield strength ≥ MPa Elongation ≥ %
T12 415 220 30
TP304 515 205 35
TP304L 458 170 35
TP316 515 205 35
TP316L 485 170 35
TP317 515 205 35
TP317L 515 205 35
TP321 515 205 35





Quality Control:

1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
