Drill Pipe Couplings Tube Machining For Drill Rods Coupling And Casing

Name: Drill Pipe Couplings Tube Machining For Drill Rods Coupling And Casing
Brand: TORICH INTERNATIONAL LIMITED
SKU: 42CrMo
Price: 40.00 USD
Availability: InStock

Brand Name:	TORICH
Model Number:	42CrMo
MOQ:	50 pcs
Price:	30-50 usd per ton
Payment Terms:	T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:	6000 pcs per month

Detail Information

Product Description

Detail Information

Place of Origin:

Zhejiang,China

Certification:

ISO 9001 ISO 14001 TS 16949

Product Name:

Tube Machining For Drill Rods Coupling And Casing,Drill Pipe Coupling From TORICH

Keyword:

Drill Pipe Coupling

Application:

For Drill Rods Coupling And Casing

Material:

1020,42CrMo,1045,35CrMo,St52,etc.

Shape:

Round

Type:

Cold Drawn

Surface:

Customized

OD:

3-150mm

WT:

0.4-15mm

Length:

Customized

Packaging Details:

Tube Machining For Drill Rods Coupling and Casing,Drill Pipe Coupling from TORICH,packing in standard marine package.

Supply Ability:

6000 pcs per month

Highlight:

thin wall steel tubing

low carbon steel pipe

Product Description

Tube Machining For Drill Rods Coupling and Casing,Drill Pipe Coupling from TORICH

Specification:
OD: 3mm-150mm
Wall thickness: 0.4mm-15mm
Tolerance of diameter: ≤±0.05mm;
Tolerance of W.T.: ≤±0.05mm;
Concentricity: ≤0.05mm
Straightness : 0.30mm/m

Note:
DN - Nominal Diameter
NPS -Nominal Pipe Size

Application:
1. High dimensional accuracy, the tolerance of inner and outer diameter size can be accurate to within 0.05mm, better tolerance can controled wihthin 0.025mm. Precision H8-H10
2. Good surface smoothness finish;
3. Good cleanliness, inside and outside surface no oxide layer
4. Can withstand high pressure, cold bending, flaring flattening, without cracking/ wrinkled
5. Excellent overall performance, can make a variety of complex deformation and machining.

Application:
For mechanical engineering
For mechanical and pressure use,and also for transporting steam,water,gas and etc.
ASTM A519 specification covers for several grades of carbon and alloy steel mechanical tubing, either hot-finished or cold-finished.
1.Auto parts ;Gas spring;Motor housing, dc motor;Industrial processing: machine parts, bearing sleeve, Hydraulic cylinder ,air cylinder;Other: electrical gas transmission, water generation fluid pipeline, etc.

Processing	Cylinder diameter	Length /mm	Straightness	Size accuracy	Wall thickness/mm	Inner bore roughness
Cold-drawn	ID50~OD325	≤12m	0.3~0.8mm/m		±8%	0.8~1.6um
Honed tube	ID50~OD325	≤10m	0.3~0.8mm/m	H8~H9	±8%	0.2~0.6um
