HC420 HC340 Cold Drawn Welded Steel Tube for Automotive Industry

HC420 HC340 Cold Drawn Welded Steel Tube for Automotive Industry

MOQ: 6 Tons
Price: 650-750USD
Standard Packaging: oil antirust+in hexagonal bundles
Delivery Period: 6-9weeks
Payment Method: L/C, T/T, L/C, D/A, D/P, T/T, Western Union,
Supply Capacity: 6000 Metric Ton/Metric Tons per Month
Detail Information
Place of Origin
China
Brand Name
TORICH
Certification
ISO9001
Model Number
ASTM A135
Material:
HC420 HC340
Type:
Electric-Resistance-Welded Steel Pipe
Outer Diameter:
5 - 420 Mm
Production Technology:
Cold Draw/Cold Rolled/Hot Rolled
Surface Treatment:
Black Varnish Painted,oil Painted,Galvanized
Alloy Or Not:
Not Alloy
Highlight:

welding steel tubing

,

electric resistance welded steel tube

Product Description

HC420 HC340 19.1X1.2 Cold Drawn Welded Steel Tube for Automotive Industry

Specifications

Standard:
ASTM A135 Standard Specification for Electric-Resistance-Welded Steel Pipe


Material:HC420 HC340



Application:
1. Low and middle pressure fluid transportation pipeline
2. Casing Tube
3. Boiler Pipe
4. Petroleum and natural gas industry
5. Chemistry industry
6. Electric industry

Surface Treatment:
1.Bared
2.Black Painted (varnish coating)
3.Galvanized
4.Oiled

5.PE,3PE, FBE, corrosion resistant coating, Anti corrosion coating.

Table  TUBING WALL THICKNESS TOLERANCE
Nominal
Wall Thickness
Nominal OD
Through 22mm
±mm
Nominal OD
22-48mm
±mm
Nominal OD
48-100mm
±mm
0.89 0.05/0.05 0.05/0.05 0.05/0.05
1.00 0.05/0.05 0.05/0.08 0.05/0.08
1.25 0.05/0.05 0.05/0.08 0.05/0.08
1.50 0.05/0.05 0.05/0.08 0.05/0.08
1.65 0.05/0.05 0.05/0.08 0.05/0.08
2.00 0.05/0.05 0.05/0.08 0.05/0.08
2.11 0.05/0.05 0.05/0.08 0.05/0.08
2.410 0.05/0.05 0.05/0.08 0.08/0.08
2.500 0.05/0.08 0.05/0.10 0.08/0.08
2.770 0.05/0.08 0.05/0.10 0.08/0.08
3.000 0.05/0.08 0.05/0.10 0.08/0.08
3.050 0.05/0.08 0.05/0.10 0.08/0.08
3.40 - 0.05/0.10 0.08/0.08
3.75 - 0.05/0.10 0.08/0.08
4.00 - 0.08/0.10 0.08/0.10
4.19 - 0.08/0.10 0.08/0.10
4.57 - 0.10/0.10 0.08/0.13
5.00 - 0.10/0.13 0.10/0.13
Table 2- CHEMICAL REQUIREMENTS
Element %
Carbon 0.06-0.18
Manganese 0.30 to 0.60
Phosphprus 0.040 max
Sulfur 0.050 max
Table 3- MECHANICAL PROPERTIES
Properties Value
Yield Strength,min 170 Mpa
Ultimate Strength,min 310 Mpa
Elongation in 50mm, min 35%
Hardness ( Rockwell B),max 65.00

Sizes: OD:5-420 mm WT: 0.5mm-50mm L:max 12000mm


Description:

MechaniCal tubing made from hot or cold-rolled steel.

Covers electric-resistance-welded low carbon steel tubing for use as mechanical tubing



HC420 HC340 Cold Drawn Welded Steel Tube for Automotive Industry
HC420 HC340 Cold Drawn Welded Steel Tube for Automotive Industry

QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking


100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
