| Brand Name: | TORICH |
| Model Number: | ASTM A36/A36M |
| MOQ: | 5Tons |
| Price: | USD700-1000/Ton |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 2000Tons per Year |
| Product Name | TORICH ASTM A36/A36M Carbon Structural Steel for general structural purposes |
| Brand | TORICH |
| Standard | ASTM A36 |
| Grade | 10#, 20#, Q195, Q215, Q235 etc |
| Technic | Cold-Drawn |
| Used | structural purposes |
Tensile Requirements
| Plates, Shape and Bars: Tensile strength, ksi [Mpa] Yield point, min, ksi [MPa] | 58-80 [400-550] 36 [250] |
| Plates and Bars: Elongation in 8 in.[200mm], min, % Elongation in 2 in.[50mm], min, % | 20 23 |
| Shape: Elongation in 8 in.[200mm], min, % Elongation in 2 in.[50mm], min, % | 20 21 |
Chemical Requirements
| Product | Shapes | Bars; Plates≤15-in. [380mm] Width | |||
| Thichness, in.[mm] | All | To 3/4 [20], incl | Over 3/4 to 1 1/2 [20to40], incl | Over 1 1/2 to 4 [100], incl | Over 4[100] |
| C, max, % | 0.26 | 0.26 | 0.27 | 0.28 | 0.29 |
| Mn, % | --- | --- | 0.60-0.90 | 0.60-0.90 | 0.60-0.90 |
| P, max, % | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 |
| S, max, % | 0.05 | 0.05 | 0.05 | 0.05 | 0.05 |
| Si, % | 0.40 max | 0.40max | 0.40max | 0.40max | 0.40max |
| Cu, min, % when cop per steel is specified | 0.20 | 0.20 | 0.20 | 0.20 | 0.20 |
A6/A6M Specification for General Requirements for Rolled Structural Steel Bars, Plates, Shapes, and Sheet Piling
A27/A27M Specification for Steel Casting, Carbon, for General Application
A500 Specification for Cold-Formed Welded and Seamless Carbon Steel Structral Tubing in Rounds and Shapes
A501 Specification for Hot-Formed Welded and Seamless Carbon Steel Structral Tubing
A502 Specification for Rivets, Steel, Structural
QUALITY CONTROL:
1. Incoming Raw Material Inspection
2. Raw Material Segregation to avoid steel grade mix-up
3. Heating and Hammering End for Cold Drawing
4. Cold Drawing and Cold Rolling, on line inspection
5. Heat Treatment, +A, +SRA, +LC, +N, Q+T
6. Straightening-Cutting to specified length-Finished Measuring Inspection
7. Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8. Packing and Stocking
100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
Products Show
Stress Relieved Structural Steel Pipe Hollow Stainless Steel Rod Mirror Finished
Cold Drawn Carbon Steel Astm A311 Surface For Shock Absorber Piston
Seamless Seel Tubes are packed in wooden boxes or hexagonal bundles in seaworthy packing.
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples of carbon seamless steel tube ? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
TORICH ASTM A36/A36M Carbon Structural Steel for general structural purposes
