Welded Drawn Seamless Boiler Tube Low Carbon Steel Precision Astm A178
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO 9001 ISO14001
Model Number:
A178/A178M
Trading Properties
Minimum Order Quantity:
8tons
Price:
1100-1300USD/ton
Payment Terms:
L/C, T/T
Supply Ability:
5000tons/year
Product Summary
Low carbon steel Precision ASTM A178 Welded and Drawn Boiler Tubes A178A Electric-Resistance-Welded Carbon Steel and Carbon-Manganese Steel Boiler and Superheater Tubes Welded steel tubes Precious tolerance tubes A178 Gr A is widely apply in boiler,exchanger and condensers,Its super heat resistant ...
Product Details
Highlight:
welding steel tubing
,electric resistance welded steel tube
Material:
Low Carbon Steel
Standard:
A178/A178M
Certificate:
ISO9001 TS16949
Length:
12m Max
MOQ:
8 Tons
Production Method:
ERW
Heat Treatment:
Yes
Steel Grade:
Gr A Gr B Gr C
Product Description
Low carbon steel Precision ASTM A178 Welded and Drawn Boiler Tubes
A178A Electric-Resistance-Welded Carbon Steel and Carbon-Manganese Steel Boiler and Superheater Tubes
Welded steel tubes Precious tolerance tubes A178 Gr A is widely apply in boiler,exchanger and condensers,Its super heat resistant ,make good performace in application.
Torich A178 Gr A Passed SGS inspection,Good quality is culture.
Material Gr A,Gr C,Gr D.
Welded steel tubes Chemical requirement
| Element | Composition % | ||
| Gr A Low-carbon steel | GrB Medium-Carbon Steel | Grade D,Carbon Manganese Steel | |
| Carbon | 0.06-0.18 | 0.35Max | 0.27Max |
| Manganese | 0.27-0.63 | 0.80Max | 1.00-1.50 |
| Phosphorus,Max | 0.035Max | 0.035Max | 0.030 |
| Sulfur,Max | 0.035Max | 0.035Max | 0.015 |
| Sillicon | 0.10Min | ||
Welded steel tubes Mechanical Testing Required
Flattening Test
Flange Test
Crush Test
Tension Test
Reverse Flattening Test
Application for
Boilers
Heat exchangers
Condensers
Pressure vessels
Characteristic:
Low carbon steel
Super heat resistant
Samples are avaliable.
