SA1D ERW Type Welded Aluminized Steel Tube For Exhaust System

Name: SA1D ERW Type Welded Aluminized Steel Tube For Exhaust System
Brand: TORICH INTERNATIONAL LIMITED
SKU: JIS G3314
Price: 1,050.00 USD
Availability: InStock

Brand Name:	TORICH
Model Number:	JIS G3314
MOQ:	10 tons
Price:	900-1200 usd per ton
Payment Terms:	T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:	50000 tons per year

Detail Information

Product Description

Detail Information

Place of Origin:

Zhejiang,China

Certification:

ISO 9001 ISO 14001 TS16949

Product Name:

JIS G3314 SA1D 38.1*1.6 Welded Aluminized Steel Tubes

Keyword:

Aluminized Steel Tubes

Application:

For Exhaust System

Type:

ERW/HFW

Shape:

Round

Material:

1010,1020,1045,SPHC,SPCC,4130

Length:

Max12000mm

OD:

5-420mm

WT:

0.5-50mm

Brand:

TORICH

Packaging Details:

JIS G3314 SA1D 38.1*1.6 Welded Aluminized Steel Tubes,packing in standard marine package

Supply Ability:

50000 tons per year

Highlight:

Exhaust System Aluminized Steel Tube

ERW Aluminized Steel Tube

Aluminized Steel Tube SA1D

Product Description

**JIS G3314 SA1D 38.1*1.6 Welded Aluminized Steel Tubes**

ASTM A513 Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing

Size : O.D.:6-350mm W.T.:1-12.5mm L:max12000mm

Grade: 1008,1010, 1020, 1026

Production: ERW + DOM

Steel Grade and Chemical Compositions:
Steel Grade	C	Mn	P	S	Si	Cr	Mo
Steel Grade	max		max	max	max	min
1008	0.10	0.5	0.035	0.035
1010	0.08-0.13	0.30-0.60	0.035	0.035
1018	0.14-0.20	0.30-0.60	0.035	0.035
1020	0.17-0.23	0.30-0.60	0.035	0.035
1026	0.22-0.28	0.60-0.90	0.035	0.035
1035	0.31-0.38	0.60-0.90	0.035	0.035
4130	0.28-0.33	0.40-0.60	0.035	0.035	0.15-0.35	0.80-1.10	0.08-0.25
4140	0.38-0.43	0.75-1.00	0.035	0.035	0.15-0.35	0.80-1.10	0.15-0.25
