Hydraulic Cylinder Tube

Products Description TORICH JIS G3473 Hydraulic Cylinder Round Carbon Honed Tube Product Name JIS G3473 Hydraulic Cylinder Round Carbon Honed Tube Brand TORICH Standard JIS G3473 Hydraulic Cylinder Carbon Steel Tubes for Cylinder Barrels Reference Standard GB/T222, GB/T223, GB/T228, GB/T241, GB/T245 etc Material STC 370, STC440, STC510A, STC510B, STC540, STC590A, STC590B Application Cylinder Barrels Chemical Composition Grade C Si Mn P S Nb or V STC 370 0.25 0.35 0.30-0.90 0

Product Description TORICH Hydraulic Cylinder Tube E355 ST52 H8 Honed Tube Manufacture Method: Cold drawn, hot rolled+deep hole bored Certification: ISO9001, SGS, Material: Carbon steel,alloy steel, stainless steel Standard&Grade: DIN2391-2 ST52,EN10305-1 E355,C45E,25CrMo4,42CrMo4, CK45,E410, E470,ASTM A519 SAE1020,SAE1026,SAE1045,SAE1518,SAE1541, SAE4130,SAE4140,SAE4145,SAE4340,etc. Size Range: ID of 300mm max for cold drawing, ID of 500mm for deep hole boring ID Tolerance:

EN10305-4 E215 E235 E355 High Precision Seamless Hydraulic Cylinder Honed Tube Product Description The saemless hydrualic cylinder honed tube is produced in strict accordance with the European EN10305-4 standard. Carbon steel pipe billets are used as raw materials, treated with imported lubricants from Europe, and manufactured by precision cold drawing. The ENstandard series of high-brightness precision seamless flat oval steel pipes have high dimensional accuracy and bright

Products Description TORICH DIN17175 engineering and agricultural machinery Seamless Steel Honed Tube Standard DIN17175, DIN2391 Material 20#, 45#, Q345 Size OD: 5-120mm WT: 0.5-50 Length: 3-9m Delivery Condition + Cc + LCc + SR + Ad + N Test Tensile Test, Hydraulic Test, Eddy Current Test etc Application Hydraulic Pipe Mechanical Requirements Delivery Condition Cold Finished (Hard) (BK) Cold Drawn and Stress-Relieved (BK+S) Hardness HB Parameters T.S. Rm N/mm2 Elongation A5%

EN 10305-1 E235 E355 St52 Seamless Carbon Steel Hydraulic Cylinder Honed Tube 1. Material: ST45, ST52, E355, E355SR, STKM13C, SAE1026, 20#, Q235B, CK45, CK20, 16Mn, 27SiMn etc 2. Standard: DIN2391, EN10305, DIN17175 etc 3. OD: 40-400mm 4. WT: 5-40mm 5. Length: Random (5-7m) or Fixed length as per order of confirmation 6. Polishing: To 0.4Ra Max 7. Supply Condition: BK(+C), BK+S (+SR)  8. Technology: Honed & SRB (SKIVED AND ROLLER BURNISHED ) 9. Tolerance: Inner Diameter: ISO

Astm A276 Stainless Steel Rod S30403 Stainless Steel bar Product Description: Stainless steel round bar besides having the characteristics or corrosions resistance has been developed over time to encapsulate end user applications. For example, Improved Machining (IM) grades have been developed to enhance machining of the steel into components, grades for hardness by responding to heat treatment and grades with high corrosion qualities by adding additional elements to give it

EN10305-1 E235 +SRA CDS Hydraulic Cylinder Tubes for Pneumatic Cylinders Tube and Telescopic Systems Standard: EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes Steel tubes for precision applications. Applications: for Auto industry/for machinery use/Oil Cylinder Tube/Motorcyle shock absorber Auto shock absorber inner cylinder/Telescopic Cylinders Size range: O.D.:6-350mm W.T.:1-35mm L:max12000mm Production: Cold Drawn + Honing + Skiving + Roller Burnish Steel Grade and

TORICH Seamless Pipe CK45 Shock Absorber ISO9001 BKS Honed Steel Tube ST52 E355 BKS Shock Absorber Using CK45 AISI1020 AISI1045 CDS Honed Tube Material: Carbon Steel Tube Outer Diameter: 30-250mm Wall Thickness: 2-30mm Material Grade: ST52,E355,CK45,A106,A53,SKTM11A,STKM13A,STKM13C,S45C,and so on Delivery Condition: BK/BKS/GBK/NBK Delivery time: within 20-30 days after receiving prpayment Trade Terms: any other China main port Manufacture Method: Cold drawn, hot rolled+deep

EN10305-1 Seamless Round Hydraulic Cylinder Honed Tube Standard: EN10305-1 Steel Grade: E 235 E355 Etc Material: Carbon And Alloy Steel Grade Dimension: O.D.:6-380mm W.T.:1-35mm L:max12000mm WT Tolerance: +/-0.15mm Production Method: Seamless Cold Drawn/Rolling Delivery Condition: +Cc +LCc +SR +Ad +N NBK Applications: Hydraulic Cylinder/Oil Cylinder Tube/Excavator Chains and Parts a: Rm: tensile strength; ReH: upper yield strength; A: elongation after fracture b: 1Mpa=1N/mm2
