Oiled Hydraulic Cylinder Tube ASTM A519 Carbon Mechanical Steel Tubing Plain End
Product Details
honed hydraulic cylinder tube
,hydraulic cylinder pipe
Products Description:
50mm ASTM A519 Carbon Steel Mechanical Tube Hydraulic Cylinder Pipe
ASTM A519 1010 1020 +SRA +N CDS Precision Hydraulic Cylinder Steel Tube
Oil cylinder Seamless Carbon and Alloy Steel Mechanical Tubing ASTM A519
O.D.: 50-350mm
W.T.:0.5-35mm
L:max12000mm
1. ASTM A519 Oil cylinder Seamless Carbon and Alloy Steel Mechanical Tubing
2. Steel Grade: SAE1010,SAE1020,SAE1026,SAE4130,SAE4140
3. Porudction Method: Cold drawing + Honing + Skiving Roller Bunish
4. Packing: Could be in Cartons or Wooden Box
We offer Cut to short lengths according to customer reqirement and drawings.
Grade and Chemical Composition ( % )
| Grade | C | Mn | P≤ | S≤ | Si | Cr | Mo |
| 1008 | ≤ 0.10 | 0.30-0.50 | 0.040 | 0.050 | - | - | - |
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1025 | 0.22-0.28 | 0.30-0.60 | 0.040 | 0.050 | - | - | - |
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 | - | - | - |
| 4130 | 0.28-0.33 | 0.40-0.60 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
| 4140 | 0.38-0.43 | 0.75-1.00 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
Mechanical properties
| Grade | Condition | Tensile Point (Mpa) | Yield Point (Mpa) | Elongation |
| 1020 | CW | ≥ 414 | ≥ 483 | ≥ 5% |
| SR | ≥ 345 | ≥ 448 | ≥ 10% | |
| A | ≥ 193 | ≥ 331 | ≥ 30% | |
| N | ≥ 234 | ≥ 379 | ≥ 22% | |
| 1025 | CW | ≥ 448 | ≥ 517 | ≥ 5% |
| SR | ≥ 379 | ≥ 483 | ≥ 8% | |
| A | ≥ 207 | ≥ 365 | ≥ 25% | |
| N | ≥ 248 | ≥ 379 | ≥ 22% | |
| 4130 | SR | ≥ 586 | ≥ 724 | ≥ 10% |
| A | ≥ 379 | ≥ 517 | ≥ 30% | |
| N | ≥ 414 | ≥ 621 | ≥ 20% | |
| 4140 | SR | ≥ 689 | ≥ 855 | ≥ 10% |
| A | ≥ 414 | ≥ 552 | ≥ 25% | |
| N | ≥ 621 | ≥ 855 | ≥ 20% |
How is your production capability?
1.2000 tons monthly production capacity, 5000 tons monthly trading capability
2.Prompt and Timely shipment
How to get the sample?
1.You are requested to pay for sample charges and courier charges from China to your country; and the free sample is according the product like size, steel grade and quantity, please consult our sales for details
2.Sample charges will be refunded when order is placed.
What is your Payment Term?
1.T/T: 30% deposit in advance, the balance 70% paid before shipment
2.30% down payment, the balance 70% paid against L/C at sight
3.Upon negotiation
Who are your customers?
1.Stockists, Distributors,Wholesalors,Agents, Traders, End Users, etc
How long will you react on our requirement?
1.Your requirement would be treated within 24 hours on weekdays. Quotations would be sent upon technical details confirmed by customer!
Any more questions about your doubts, please feel free to send us your emails or call!
-
