ASTM A213 Pickled Cold Rolled Annealed Tube Boiler / Heat Exchangers
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO9001
Model Number:
ASTM A213
Trading Properties
Minimum Order Quantity:
1ton
Price:
$1200-$1500
Payment Terms:
L/C, D/A, D/P, T/T, Western Union
Supply Ability:
5000tons per year
Product Summary
ASTM A213 Boiler / Heat Exchangers Annealed Pickled Stainless Seamless Steel Tube Product Name Boiler steel tube Material 304 316 T11 T22 Type Seamelss Standard ASTM A213 Grade 304, 304L, 316L, 321, 347, 904L Size 5-420 mm Length 800mm - 11800 mm Used bolier, heat exchanger Tolerance for seamless ...
Product Details
Highlight:
stainless tube steel
,large diameter stainless steel tube
Standard:
ASTM A213
Grade:
T11, T22
Type:
Seamless
Delivery Condition:
Pickled And Annealed
Application:
Boiler And Heat Exchanger
Length:
5.8m Or 6m Or 11.8 Or Customer's Requirement
Product Description
ASTM A213 Boiler / Heat Exchangers Annealed Pickled Stainless Seamless Steel Tube
| Product Name | Boiler steel tube |
| Material | 304 316 T11 T22 |
| Type
| Seamelss |
| Standard | ASTM A213 |
| Grade | 304, 304L, 316L, 321, 347, 904L |
| Size | 5-420 mm |
| Length | 800mm - 11800 mm |
| Used | bolier, heat exchanger |
Tolerance for seamless stainless boiler tube:
| Production Method | Size(mm) | Tolerance | |
| Hot Rolling(Extrusion) | OD | ≤140 | ±1.25% |
| ＞140 | ±1.0% | ||
| WT | ≤10 | ±12.5% | |
| ＞10 | ±15% | ||
| Cold Drawn(Cold Rolled) | OD | 8~30 | ±0.20mm |
| ＞30~50 | ±0.30mm | ||
| ＞50 | ±0.8% | ||
| WT | 1.0~3 | +12% -10% | |
| ＞3.0 | ±10 | ||
316 stainless steel.Composition
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 316 | Min | - | - | - | 0 | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.08 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
| 316L | Min | - | - | - | - | - | 16.0 | 2.00 | 10.0 | - |
| Max | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
| 316H | Min | 0.04 | 0.04 | 0 | - | - | 16.0 | 2.00 | 10.0 | - |
| max | 0.10 | 0.10 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | - |
Mechanical Properties
| Grade | Tensile Str (MPa) min | Yield Str 0.2% Proof (MPa) min | Elong (% in 50 mm) min | Hardness | |
|---|---|---|---|---|---|
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 316 | 515 | 205 | 40 | 95 | 217 |
| 316L | 485 | 170 | 40 | 95 | 217 |
| 316H | 515 | 205 | 40 | 95 | 217 |
| Grade | Density(kg/m3) | Elastic Modulus (GPa) | Mean Co-eff of Thermal Expansion (µm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100 °C (J/kg.K) | Elec Resistivity (nΩ.m) | |||
|---|---|---|---|---|---|---|---|---|---|
| 0-100 °C | 0-315 °C | 0-538 °C | At 100 °C | At 500 °C | |||||
| 316/L/H | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
Mechanical property
Heat treatment of longitudinal mechanical properties of steel pipe shall according to the standard.
| Material | Tensile strength MPa ≥ | Yield Strength MPa ≥ | Elongation % ≥ |
| 0Cr18Ni9 | 520 | 205 | 35 |
| 1Cr19Ni9 | 520 | 205 | 35 |
| 0Cr19Ni10 | 480 | 175 | 35 |
| 1Cr18Ni9Ti | 550 | 205 | 40 |
| 0Cr18Ni12Mo2Ti | 530 | 205 | 35 |
| 0Cr26Ni5Mo2 | 590 | 390 | 18 |
| 1Cr17 | 410 | 245 | 20 |
| 00Cr27Mo | 410 | 245 | 20 |
| 1Cr25Ti | 440 | 245 | 17 |
Hardness:
For the tubes which W.T. ≥2 mm, Rockwell hardness tests should be taken.
Tests of the seamless boiler tubes:
1.Bending Test:
The tubes should take the bending test when OD ≤22mm. The bending angle is 90 degrees, and the bending radius is 6 times the outer diameter of the steel tube.
2. Hydraulic test;
Eddy current testing, ultrasonic testing can be used instead of hydraulic tests. When eddy current testing, GB/T 7735-1995 Gr. A should be followed; when ultrasonic testing, GB/T 5777-1996 Gr. C8 should be followed.
3. Flattening test
4. Flanging test
5. Expand test
