Ferritic / Martenstic Stainless Steel Tube Astm A268 Tp304 Seamless Iso Certificated
Product Details
stainless tube steel
,large diameter stainless steel tube
ASTM A268 TP304 Seamless Ferritic and Martenstic Stainless Steel Tubing
Size range: O.D.:4-230mm W.T.:1-30mm L: according to customer requirement
Steel Grade and Chemical Compositions:
TP405, TP410, TP429, TP430, TP443, TP446-1, TP446-2, TP409
| Grade: | TP4 05 | TP4 10 | TP2 49 | TP4 30 | TP4 43 | TP4 46-1 | TP4 46-2 | … | TP4 09 |
| UNS | S40500 | S41000 | S42900 | S43000 | S44300 | S44600 | S44600 | S40800 | S40900 |
| C, max | 0.08 | 0.15 | 0.12 | 0.12 | 0.20 | 0.20 | 0.12 | 0.08 | 0.08 |
| Mn,max | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.50 | 1.50 | 1.00 | 1.00 |
| P, max | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | 0.04 | 0.045 | 0.045 |
| S, max | 0.03 | 0.03 | 0.03 | 0.03 | 0.03 | 0.03 | 0.03 | 0.045 | 0.045 |
| Si, max | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 |
| Ni | 0.50max | … | … | … | 0.75max | 0.75max | 0.50max | 0.80max | 0.50max |
Cr | 11.5- 14.5 | 11.5- 13.5 | 14.0- 16.0 | 16.0- 18.0 | 18.0- 23.0 | 23.0- 27.0 | 23.0- 27.0 | 11.5- 13.0 | 10.5- 11.7 |
| Mo | … | … | … | … | … | … | … | … | … |
| Al | 0.10- 0.30 | … | … | … | … | … | … | … | … |
| Cu | … | … | … | … | 0.90- 1.25 | … | … | … | … |
| N | … | … | … | … | … | 0.25 | 0.25 | 12xCmin | 6xCmin |
| Ti | … | … | … | … | … | … | … | 1.10max | 0.75max |
Manufacture:
Tubes are made by the seamless process.
Heat treatment:
As a final treatment, tubes shall be reheated to a temperature of 1200℉(650℃) or higher and cooled (as appropriate for the grade) to meet the requirements of this specification.
The martensitic grade UNS S41500 shall be reheated to a temperature of 950℉ (510℃) or higher and cooled as appropriate to meet the requirements of this specification.
Surface Condition:
The finished tubes are free of scale., slight amount of oxidation is not considered as scale.
Test and Inspection:
Mechanical Test
- Tension Test
- Flaring Test
- Flange Test
- Reverse Test
- Hardness Test
- Hydrostatic or Nondestructive Electric Test
Applications: for general corrosion-resisting and high-temperature service.
-
