Name: Small Diameter Hydraulic Cylinder Tube Carbon Steel Seamless With Thick Wall
Brand: TORICH INTERNATIONAL LIMITED
SKU: ASTM A53-2007
Price: 3000 USD
Availability: InStock

Home > products > Hydraulic Cylinder Tube >

Small Diameter Hydraulic Cylinder Tube Carbon Steel Seamless With Thick Wall

honed hydraulic cylinder tube

hydraulic cylinder pipe

Place of Origin:

Zhejiang China

Brand Name:

TORICH

Certification:

ISO

Model Number:

ASTM A53-2007

Request A Quote

Product Details

Standard:

ASTM, DIN, GB, JIS

Grade:

10#, 20#, 45#, 16Mn, A213

Thickness:

0.5 - 8 Mm

Outer Diameter(Round):

3 - 80 Mm

Alloy Or Not:

Non-alloy

Color Of Steel Tube:

Slivery

Tensile Strength Of Steel Tube::

≥ 410(MPa)

Yield Strength Of Steel Tube:

≥205 (MPa)

Highlight:

honed hydraulic cylinder tube

hydraulic cylinder pipe

Payment & Shipping Terms

Minimum Order Quantity

5 TONS

Price

USD 3000 per Ton

Packaging Details

Sackcloth with several steel strips

Delivery Time

3-6 weeks

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

500 Tons per Month

300L - 3000L Seamless Steel Tubes for Large Volume Gas Cylinder GB 28884

Get Best Price

video

Cold Drawn Seamless Hydraulic Cylinder Tube EN10305-1 Carbon Steel

Get Best Price

video

Cold Drawn Hydraulic Cylinder Tube ASTM A519 40-400mm ID

Get Best Price

video

EN10305-2 St52 Welded Cold Drawn Hydraulic Cylinder Tube

Get Best Price

86-574-88086983

Contact Now

Product Description

JIS S10C Small Diameter Seamless Capillary Steel Tube

Chemical Composition(%)									Mechanical Property
C	Si	Mn	S	P	Cr	Ni	Cu	Mo	Yield Strength	Tensile Strength
									( σs )	( σb )
0.07~0.14	0.17~0.37	0.35~0.65	≤0.04	≤0.35	≤0.15	≤0.25	≤0.25	/	≥205(25) (MPa)	≥ 410(42)
										(MPa)
End Shape	Beveled end, plain end, vanished, or adding plastic caps to protect the two ends as per customer's requirements
Surface	Oiled, Galvanized, Phosphate etc
Treatment
Technique	Cold drawn
Application	1. Automotive and mechanical pipes
	2. Petroleum cracking pipes
	3. High Pressure Boiler Pipe
	4. Low and middle pressure fluid transportation pipeline
	5. Chemical fertilizer equipment pipes
	6. Heat exchanger pipes
Delivery	1. BK (+C)	No heat treatment after last cold forming process.
Conditions	2. BKW (+LC)	After last heat treatment there is a light finishing pass (cold drawing)
	3. BKS (+SR)	After the final cold forming process the tubes are stress relieve annealed.
	4. GBK (+A)	After the final cold forming process the tubes are annealed in a controlled atmosphere.
	5. NBK (+N)	After the final cold forming process the tubes are annealed above the upper transformation point in acontrolled atmosphere.
Package	1. Bundle Packing.
	2. Plain end or vanished as per customer's request.
	3. Wrapped in waterproof paper.
	4. Sackcloth with several steel strips.
	5. Pack in heavy tri-wall boxes.

QUALITY CONTROL

1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.

Q: Are you trading company or manufacturer ?

A: A professional steel pipes materials inventor, manufacturer and solution provider

Q: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
