Name: Cold Drawn Precision Steel Tubes EN10305-2 E235 E355
Brand: TORICH INTERNATIONAL LIMITED
SKU: EN10305-2
Price: 1,150.00 USD
Availability: InStock

Home > products > Precision Steel Tube >

Cold Drawn Precision Steel Tubes EN10305-2 E235 E355

E235 Precision Steel Tubes

Precision Steel Cold Drawn Tube

Shock Absorber Precision Steel Tube

Place of Origin:

ZHEJIANG, CHINA

Brand Name:

TORICH

Certification:

CE,ISO

Model Number:

EN10305-2

Request A Quote

Product Details

Standard:

EN10305-2

OD:

5-420mm

WT:

0.5-50mm

Length:

Max12000mm

Material:

E215 E235 E355

Technique:

Cold Drawn

Application:

Shock Absorber，oil Cylinder Tube，machinery Use

Alloy Or Not Alloy:

Not Alloy

Highlight:

E235 Precision Steel Tubes

Precision Steel Cold Drawn Tube

Shock Absorber Precision Steel Tube

Payment & Shipping Terms

Minimum Order Quantity

1ton

Price

800-1500USD/TON

Packaging Details

in bundles or in wooden box

Delivery Time

10-15days

Payment Terms

L/C, D/A, D/P, T/T

Supply Ability

60000 Tons Per year

A500 Carbon Steel Square Tube High Strength Carbon Steel Structural Tubing For Building Structure

Get Best Price

video

AISI 4140 Seamless Tubing Medium Carbon Alloy Steel Seamless Pipe For Mechanical

Get Best Price

video

TP409 Ferritic Stainless Steel Seamless Tube For General Service

Get Best Price

video

ASME SA179 Seamless Carbon Steel Tubing Cold-Drawn Low-Carbon Steel Tube For Heat-Exchanger

Get Best Price

86-574-88086983

Contact Now

Product Description

Cold Drawn Steel Tube Precision Steel Tubes EN10305-2 E235 E355 Steel Tube

Torich International Limited is a professional manufacturer and exporter of steel tubes.

It is an international marketing and sales company specialized in steel tubes, which holds the factories of Steel Tubes.

Our main products are precision cold drawn tubes, the material we usually use for precision steel tubes is E215 E235 E355.We have many years export experience of Welded Cold Drawn Precision Steel Tubes.

Size range of precision steel tubes:

OD:5-420MM

WT:0.5-50MM

Length:≤12000MM

Steel grade: E215,E235,E355,E155,E195...

Technical:welded cold drawn

Application:

for precision applications

auto industy

for machinery use

oil cylinder tube

motorcycles shock absorber

The table below shows the chemical composition and mechanical properties of E235 and E355 steel grades:

Material	Chemical Composition (% max)	Mechanical Properties
E235	C: 0.17, Si: 0.35, Mn: 1.20	Tensile Strength: 440 MPa, Yield Strength: 235 MPa
	P: 0.025, S: 0.025	Elongation: 25%, Hardness: 84 HRB
E355	C: 0.22, Si: 0.55, Mn: 1.60	Tensile Strength: 640 MPa, Yield Strength: 355 MPa
	P: 0.025, S: 0.025	Elongation: 22%, Hardness: 92 HRB

Steel grade and chemical compositions:

Steel Grade		C	Si	Mn	P	S
Steel name	Steel number	max	max	max	max	max
E215	1.0033	0.11	0.35	0.7	0.03	0.025
E235	1.0034	0.15	0.35	0.7	0.03	0.025
E355	1.0308	0.17	0.35	1.2	0.03	0.025
E235	1.0225	0.21	0.35	1.4	0.03	0.025
E355	1.0580	0.22	0.35	1.6	0.03	0.025

Delivery conditions:

Designation	Symbol^a	Description
Cold drawn/hard	+C	No final heat treatment after final cold drawing
Cold drawn/soft	+LC	Final heat treatment is followed by a suitable drawing pass(limited reduction of area)
Cold drawn and stress relieved	+SR	After final cold drawing the tubes are stress relieved in a controlled atmosphere
Soft annealed	+A	After final cold drawing the tubes are annealed in a controlled atmosphere
Normalized	+N	After final cold drawing the tubes are normalized in a controlled atmosphere
^aIn accordance with EN10027-1

Workshop for Welded Cold Drawn Precision Steel Tubes:

Cold Drawn Precision Steel Tubes EN10305-2 E235 E355 0

Cold Drawn Precision Steel Tubes EN10305-2 E235 E355 3

Cold Drawn Precision Steel Tubes EN10305-2 E235 E355 4

Certification for Welded Cold Drawn Precision Steel Tubes

Cold Drawn Precision Steel Tubes EN10305-2 E235 E355 5

FAQ:

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-45 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples?

A: Yes, we could offer the sample

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
