Cold Drawn Seamless Tube Stainless Steel Astm A106 For Hydraulic Cylinder

Brand Name:	TORICH
Model Number:	ASTM A 106
MOQ:	100 Kgs
Price:	negotiable
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	500 Ton per Month

Detail Information

Product Description

Detail Information

Place of Origin:

Zhejiang China

Certification:

ISO

Standard::

JIS, AISI, ASTM, GB, DIN, EN

Type::

Seamless

Steel Grade::

300 Series

Material:

Stainless Steel 304/316

Outer Diameter::

40-1600 Mm

Thickness::

5-75 Mm

Tolerance:

H7, H8, H9

MTC::

Mill Test Certificate

Packaging Details:

According to the customers' requirements, such as beveled, plastic caps covered two ends, black painting, tied in bundle

Supply Ability:

500 Ton per Month

Highlight:

cold drawn steel tube

cold drawn tubes

Product Description

Stainless Honed Tube

Grade: Stainless Steel 304/316
Length: max 20 meters
Streightness: 0.5/1000
Tolerence WXT: DIN 2391
Tolerence INT: ISO H8
Roughness (Ra): 0.2 to 0.4μ
Type: Cold Drawing, stress release, BK+S, honing or Skiving

CHEMICAL COMPOSITION(%)

Si (Max)	Mn (Max)	C (Max)	S (Max)	P (Max)
0.55	1.6	0.22	0.025	0.025

MECHANICAL PROPERTIES

Tensile Strenght Min	Yield Point Min	Elongation % Mn
640 N/mm²	560 N/mm²	14

Heat treatment : BK+S

Technology : Honed & SRB(SKIVED AND ROLLER BURNISHED )

Application: for hydraulic cylinder, swivel crane, injection machine and
construction machine application

Protection : anti-rust oil on inside and outside surface, plastic caps in both ends.

Straightness: ≤ 0.5/1000

Roughness: 0.2-0.4 u

Tolerance EXT: DIN2391, EN10305, GB/T 1619
Package: Bundled with Steel Strip and Knitting Strip, or Wooden Case

Detailed Images

Torich Strength:

1. Torich is the STEEL TUBE MAKER company in China,playing a significant role in domestic market as well as international market.

2. Our products have exported to over 56 countries worldwide, winning a great fame among our customers.

3. There was no quality claim in the past 3 years.

4. First production was started since 1997, our boss worked in steel tube industry for over 10 years before started the own factory, factory engineers with over 30 years manufacturing experience, knowing well about production and inspection technology.

5. We have been exporting steel tubes since 10 years ago, and know well about international standard for steel tubes DIN/EN,ASTM,SAE,BS,GOST,JIS etc,also with great experience of International trading practices.

6. Our team take Timely action within 24 hours after receiving customers' first requirement and enquiry.

7. 100% prompt delivery in the past 3 years.

8. 100% dimensional check and 100% visual inspection on tube surfaces.

9. 100% eddy current test and ultrasonic test for detecting longitudinal and transversal defects.

10.Convenient tranportation: production location is 30 mins high speed train from Shanghai, 2 hours drive from Shanghai
