Name: Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310
Brand: TORICH INTERNATIONAL LIMITED
SKU: GB 5310
Price: 2,550.00 USD
Availability: InStock

Home > products > Seamless Steel Tube >

Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310

precision stainless steel tubing

seamless carbon steel tube

Place of Origin:

Zhejiang China

Brand Name:

TORICH

Certification:

ISO 9001 ISO 14001 TS 16949

Model Number:

GB 5310

Request A Quote

Product Details

Product Name:

High Creep Rupture Strength Seamless Steel Tubes And Pipes For High Pressure Boiler GB 5310

Material:

20G 20MnG 25MnG 15CrMoG

Surface:

With Anti Rust Oil Protection

Application:

Pipe And Tubes For High Pressure Boiler

Shape:

Round

OD:

3-1200mm

WT:

0.5-200mm

Length:

4-12.5m

Highlight:

precision stainless steel tubing

seamless carbon steel tube

Payment & Shipping Terms

Minimum Order Quantity

5 Ton

Price

negotiable

Packaging Details

Packing in wooden box，hexagonal bundles or other seaworthy ways.

Delivery Time

30 days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

50000 Ton/Year

42CrMo Alloy Steel Boiler Tube Alloy Seamless Steel Pipe Tube For Boiler

Get Best Price

20MnG High Pressure Boiler Tube Alloy Seamless Pipe For Boilers Heat Exchangers

Get Best Price

ASTM A106 Hot Finished Seamless Tubing High-Temperature Seamless Carbon Steel Pipe

Get Best Price

video

40Mn2 20Cr 40Cr 15CrMo Carbon Steel / Alloy Steel Hot Rolled Steel Tube

Get Best Price

86-574-88086983

Contact Now

Product Description

Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310

Spec:

Material:20G 20MnG 25MnG

Size Range:OD:4-1200mm

WT:0.3-200mm

General Length:4-12.5m

Tolerance:

According to the following tables or customers’ request.

Producing method	Size			Tolerance
				General	High grade
Hot rolling (extrude)	D	<54		±0.40	±0.30
		>54~325	S≤35	±0.75%	±0.5%
			S>35	±1%	±0.75%
		>325		±1%	±0.75%
	S	≤4.0		±0.45	±0.35
		>4.0~20		±12.5%-10%	±10%
		>20	D<219	±10%	±7.5%
			D≥219	±12.5%-10%	±10%
Hot expand	D	complete		±1%	±0.75%
	S			+20%-10%	+15%-10%
Cold drawn(rolling)	D	≤25.4		±0.15	_
		>25.4~40		±0.20	_
		>40~50		±0.25	_
		>50~60		±0.30	_
		>60		±0.5%	_
	S	≤3.0		±0.3	±0.2
		>3.0		±10%	±7.5%

Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310 0

Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310 1

Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310 2

Characteristic:

High Creep Rupture Strength

High antioxidant properties

Good organizational stability

Good concentricity

Good OD and ID tolerance

High Precision

Stable quality

Smooth Roughness

TORICH QUALITY ASSURANCE

Processing:

RAW MATERIAL

↓

INCOMING INSPECTION

↓

STORAGE → CUTTING→HAMMERING → PICKING LUBRICATION → CLEANING → PHOSPHORI CLEAN

↓

ENDS CUTTING←STRAIGHTENING←HEAT TREATMENT↔MIDDLLE CHECK↔ COLD DRAWING ← LUBRICATING

↓

FINAL INSPECTION→BUNDING→STORAGE

Technical Delivery Conditions:

The steel tube shall be supplied in the heat treated conditions as per the heat treatment conditions desicrebed the table given below. The heat treatmet conditions shall be indicated in the quality certification.

Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310 3

Seamless Steel Tubes and Pipes for High Pressure Boiler GB 5310 4

Widely used in the field of:High pressure boiler

Product Images:
