Name: EN10216-2 DIN17175 TORICH Cold Drawn Seamless Tube
Brand: TORICH INTERNATIONAL LIMITED
SKU: EN10216-2
Price: 2,550.00 USD
Availability: InStock

Home > products > Seamless Steel Tube >

EN10216-2 DIN17175 TORICH Cold Drawn Seamless Tube

DIN17175 cold drawn seamless tube

EN10216-2 cold drawn seamless tube

TORICH cold drawn seamless tube

Place of Origin:

ZheJiang,CHINA

Brand Name:

TORICH

Certification:

ISO9001; ISO14001; TSI16949

Model Number:

EN10216-2

Request A Quote

Product Details

Product Name:

EN10216-2, DIN17175 Seamless Carbon And Low-alloy Steel Tubes

Product Keyword:

Seamless Carbon And Low-alloy Steel Tube

Application:

For Manufacturing Pipelines Of Boilers, Vessel Equipment

Secondary:

Non-secondary

Section Shape:

Round

Technology:

Cold Drawn

Type:

Seamless

Highlight:

DIN17175 cold drawn seamless tube

EN10216-2 cold drawn seamless tube

TORICH cold drawn seamless tube

Payment & Shipping Terms

Minimum Order Quantity

5 Tons

Price

negotiable

Packaging Details

packing in hexagonal bundles wooden boxes

Delivery Time

30-35 days

Payment Terms

L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability

5000 Ton per year

EN10305-4 Seamless Cold Drawn Steel Tube Oiled Surface 0.5 - 50mm WT ISO9001 TS16949

Get Best Price

video

Chrome Moly Alloy Seamless Cold Drawn Steel Tube ASTM A335 P11 P12 P91

Get Best Price

video

Cold Drawn EN10305 E235 E355 Precision Applications Seamless Steel Tube

Get Best Price

video

WT 3.5mm DIN 2391 Cold Drawn St37 St45 Precision Seamless Steel Tube

Get Best Price

86-574-88086983

Contact Now

Product Description

EN10216-2 Seamless carbon and low-alloy steel tubes for pressure purposes

Standard: EN10216-2

Applications: For manufacturing pipelines of boilers, vessel equipment

Production Method: Seamless Cold Drawn

Size range: O.D.:5-420mm W.T.:0.5-50mm L:max12000mm

WT Tolerance: +/-0.15mm

Delivery Condition: +Cc +LCc +SR +Ad +N NBK

Steel Grade and Chemical Compositions:

Steel grades	CHEMICAL COMPOSITION (LADLE ANALYSIS)
Steel grades	C% max	Si% max	Mn% max	P% max	S% max	Cr% max	Mo% max	Ni% max	Al% min	Cu% max	Nb% max	Ti% max	V% max	Cr+ Cu+ Mo+ Ni% MAX
P195GH	0,13	0,35	0,70	0,025	0,020	0,30	0,08	0,30	>= 0,020	0,30	0,010	0,040	0,02	0,70
P235GH	0,16	0,35	1,20	0,025	0,020	0,30	0,08	0,30	>= 0,020	0,30	0,010	0,040	0,02	0,70
P265GH	0,20	0,40	1,40	0,025	0,020	0,30	0,08	0,30	>= 0,020	0,30	0,010	0,040	0,02	0,70
16Mo3	0,12- 0,20	0,35	0,40- 0,70	0,025	0,020	0,30	0,25- 0,35	0,30	>= 0,020	0,30	-	-	-	-
14MoV6-3	0,10- 0,15	0,15- 0,35	0,40- 0,70	0,025	0,020	0,30- 0,60	0,50- 0,70	0,30	>= 0,020	0,30	-	0,22-0,28	-	-
13CrMo4-5	0,15	0,50- 1,00	0,30- 0,60	0,025	0,020	1,00- 1,50	0,45- 0,65	0,30	>= 0,020	0,30	-	-	-	-
10CrMo9-10	0,10- 0,17	0,35	0,40- 0,70	0,025	0,020	0,70- 1,15	0,40- 0,60	0,30	>= 0,020	0,30	-	-	-	-

Mechanical Proporties:

Mechanical properties
Pipe types	Steel grades	Mechanical properties during tensile testing in room temperature							Resilience
Boiler P195GH, P235GG P265GH 16Mo3 14MoV6-3 13CrMo4-5 10CrMo9-10 Wg PN-EN 10216-2		Upper yield limit or yield strength Re or R0,2 for wall thickness of t min				Tensile strength Rm	Elongation A min%		Minimum energy average absorbed KVJ at the temperature of 0°C
		T<=16	16<T<=40	40<t<=60	60<T<=60	Tensile strength Rm	Elongation A min%		I		T
		MPa	MPa	MPa	MPa	MPa	I	t	20	0	-10	20	0
	P195GH	195	-	-	-	320- 440	27	25	-	40	28	-	27
	P235GH	235	225	215	-	360- 500	25	23	-	40	28	-	27
	P265GH	265	255	245	-	410- 570	23	21	-	40	28	-	27
	16Mo3	280	270	260	-	450- 600	22	20	40	-	-	27	-
	14MoV6-3	320	320	310	-	460- 610	20	18	40	-	-	27	-
	13CrMo4-5	290	290	280	-	440- 590	22	20	40	-	-	27	-
	10CrMo9-10	280	280	270	-	480- 630	22	20	40	-	-	27	-

Products Show:

FAQ

Q: Are you trading company or manufacturer?

A: We are a professional steel pipes materials manufacturer.

Q: How long is your delivery time?

A: Generally it takes 7-14 days if the goods are in stock or 30-60 days if there is no stock, this mainly depends on quantity.

Q: Do you provide free samples?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us.
