Name: Cold Drawn / Rolled Alloy Steel Pipe Seamless For Gear Wheel Axle Shaft
Brand: TORICH INTERNATIONAL LIMITED
SKU: 41Cr4 40Cr DIN1.7035
Price: 25,002.00 USD
Availability: InStock

Home > products > Alloy Steel Pipe >

Cold Drawn / Rolled Alloy Steel Pipe Seamless For Gear Wheel Axle Shaft

alloy steel tube

alloy steel seamless tube

Place of Origin:

ZheJiang,CHINA

Brand Name:

TORICH

Certification:

ISO14001:2008,TS16949

Model Number:

41Cr4 40Cr DIN1.7035

Request A Quote

Cold Drawn / Rolled Alloy Steel Pipe Seamless For Gear Wheel Axle Shaft

Product Details

Product Name:

Seamless Cold Drawn Or Cold Rolled Alloy Steel Tubing 41Cr4 40Cr DIN1.7035 For Gear Wheel , Axle , Shaft

Type:

Cold Rolling Cold Drawn

Surface:

Oiled

Material:

41Cr4 40Cr DIN1.7035

Usage:

For Gear Wheel , Axle , Shaft

Shape:

Round Shape

OD:

3-420mm

WT:

0.5-50mm

Highlight:

alloy steel tube

alloy steel seamless tube

Payment & Shipping Terms

Minimum Order Quantity

2 Ton

Price

negotiable

Packaging Details

packing in wooden boxes or in hexagonal bundles

Delivery Time

30-35 days

Payment Terms

T/T, D/A, D/P, L/C, Western Union, MoneyGram

Supply Ability

60000 Ton per year

Min Mpa Extruded Titanium Alloy Steel Pipe , Hot Rolled Steel TubingTA1 240

Get Best Price

video

Seamless Alloy Steel Tubing , Hot Rolled Steel Pipe 4140 / 4130 / 4140 / 42CrMo

Get Best Price

video

SCH10 ASTM B407 Nickel Iron Chromium Alloy Steel Pipe

Get Best Price

video

UNS N08825 ASTM B163 Standard Nickel Alloy Steel Pipe

Get Best Price

86-574-88086983

Contact Now

Product Description

Seamless Cold Drawn Or Cold Rolled Alloy Steel Tubing 41Cr4 40Cr DIN1.7035 For Gear Wheel , Axle , Shaft

Alloy Steel Tubes 41Cr4 40Cr DIN1.7035

Seamless Steel Tubes with alloy steel grade 41Cr440CrDIN1.7035

International equivalent:
JIS: SCr440
ASTM: 5140
ISO: 41Cr4

41Cr4DIN1.7035:
C:0.42
Si:0.25
Mn:0.70
Cr: 1.05

40Cr:
C:0.37-0.44
Si:0.17-0.37
Mn:0.50-0.80
Cr:0.80-1.10

Seamless steel tubes with these steel grade could achieve good mechanical properites with quenching and tempering heat treatment (QT), could also heat treatment with annealed.

Application:
Gear wheel, axle, shaft, etc

Mechanical properties:
Tensile strength ≥980 Mpa
Yield strength ≥785 Mpa
Elongation ≥9
Hardness ≤229HBS

For Application of Shafts and Machinery Parts:

Cold Drawn / Rolled Alloy Steel Pipe Seamless For Gear Wheel Axle Shaft 2

QUALITY CONTROL

1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.

100% of our steel tubes are dimensionally checked
100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.
100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.

Cold Drawn / Rolled Alloy Steel Pipe Seamless For Gear Wheel Axle Shaft 6
