Name: Seamless Cold Drawn Steel Tube For Bearing Ring ISO ASTM A866
Brand: TORICH INTERNATIONAL LIMITED
SKU: ASTM A866
Price: 28,750.50 USD
Availability: InStock

Home > products > Automotive Steel Tubes >

Seamless Cold Drawn Steel Tube For Bearing Ring ISO ASTM A866

low carbon steel tube

low carbon steel pipe

Place of Origin:

China

Brand Name:

Torich

Certification:

ISO 9001 ISO14001

Model Number:

ASTM A866

Request A Quote

Product Details

Highlight:

low carbon steel tube

low carbon steel pipe

Payment & Shipping Terms

Minimum Order Quantity

1 ton

Price

negotiable

Packaging Details

In export packaging

Delivery Time

60-90days

JIS G3460 Alloy Steel Pipe for low temperature service

Get Best Price

video

Torich Cold Drawn Shock Absorber Tube For Hyduaulic Power System

Get Best Price

video

Cold Drawn Hollow Copper Tube C1100 Air Conditioning Coil Tinned

Get Best Price

video

DIN2391 E235 E355 Cold Drawn Shock Absorber Pipe 10x1 12x1

Get Best Price

86-574-88086983

Contact Now

Product Description

ISO ASTM A866 Seamless Cold Drawn Steel Tube For Bearing Ring

Medium Carbon Anti-Friction Bearing Steel

Size:

Application: It is used in manufacture of anti-friction bearings

Chemical Composition
AISI/SAE	C	Mn	Si	Cr	Mo	V	UNS
1030	0.28-0.34	0.60-0.90	0.15-0.35	…	…	…	10300
1040	0.37-0.44	0.60-0.90	0.15-0.35	…	…	…	10000
1050	0.48-0.55	0.60-0.90	0.15-0.35	…	…	…	10600
1541	0.36-0.44	1.35-1.65	0.15-0.35	…	…	…	15410
1552	0.47-0.55	1.20-1.50	0.15-0.35	…	…	…	16620
4130	0.28-0.33	0.40-0.60	0.15-0.35	0.80-1.10	0.15-0.25	…	41300
4140	0.38-0.43	0.75-1.00	0.15-0.35	0.80-1.10	0.15-0.25	…	41400
4150	0.48-0.53	0.75-1.00	0.15-0.35	0.80-1.10	0.15-0.25	…	41600
5140	0.38-0.43	0.70-0.90	0.15-0.35	0.70-0.90	…	…	51400
5150	0.48-0.53	0.70-0.90	0.15-0.35	0.70-0.90	…	…	51600
6150	0.48-0.53	0.70-0.90	0.15-0.35	0.80-1.10	…	.15min	51600

Dimensional Tolerances for cold-finished coils
Size,in.(mm)	Total Tolerance,in.(mm)
Through 0.096(2.44)	0.002(0.05)
Over 0.096(2.44)-0.270(6.86),incl	0.003(0.08)
Over 0.270(6.86)-0.750(19.1),incl	0.004(0.10)

Decarburrization and surface imperfections for coils anf bars for balls and rollers
size,in.(mm)	Decarburization or Surface Imperfections per Side,max,in.(mm)
size,in.(mm)	Hot-Rolled or Hot Rolled Annealed	Cold-Finished Annealed
Through 0.250(6.35)	0.005(0.13)	0.003(0.08)
Over 0.250(6.35)-0.500(12.7),Incl	0.006(0.15)	0.004(0.10)
Over 0.500(12.7)-0.750(19.1),Incl	0.008(0.20)	0.006(0.15)
Over 0.750(19.1)-1.000(25.4),Incl	0.010(0.25)	0.008(0.20)

Decarburization and Surface Imperfections for Bars and Tubes
size,In.(mm)	Decarburization or Surface Imperfections per Side,Max,in.(mm)
	Hot-Rolled bars	Hot-Rolled Annealed		Cold-Finished Annealed
	Hot-Rolled bars	Bars	Tubes	Bars	Tubes
Through 1.000(25.4)	0.012(0.31)	0.015(0.38)	0.012(0.31)	0.012(0.31)	0.010(0.21)
Over 1.000(25.4)-2.000(50.8),Incl	0.017(0.43)	0.022(0.56)	0.020(0.51)	0.015(0.38)	0.014(0.36)
Over 2.000(50.8)-3.000(76.2),Incl	0.025(0.64)	0.030(0.76)	0.030(0.76)	0.025(0.64)	0.019(0.48)
Over 3.000(76.2)-4.000(101.6),Incl	0.035(0.89)	0.045(1.14)	0.035(0.89)		0.024(0.61)
Over 4.000(101.6)-5.000(127.0),Incl	0.055(1.40)	0.065(1.65)	0.040(1.02)		0.028(0.71)
