Name: E355 St52 16Mn Precision Steel Pipe / Hydraulic Cylinder Tube EN10305-1
Brand: TORICH INTERNATIONAL LIMITED
SKU: EN10305-1
Price: 1,400.00 USD
Availability: InStock

Home > products > Precision Steel Tube >

E355 St52 16Mn Precision Steel Pipe / Hydraulic Cylinder Tube EN10305-1

precision seamless pipe

precision pipes and tubes

Place of Origin:

China

Brand Name:

Torich

Certification:

ISO 9001 TS16949 ISO14001

Model Number:

EN10305-1

Request A Quote

Product Details

Material:

E355 St52 16Mn

Standard:

EN10305-1

OD:

20-450mm

WT:

0.5-20mm

Length:

12m Max

End:

Plain

Highlight:

precision seamless pipe

precision pipes and tubes

Payment & Shipping Terms

Minimum Order Quantity

2 tons

Price

1300-1500USD/ton

Packaging Details

In bundles or in wooden boxes packaging

Delivery Time

5-8 week days

Payment Terms

L/C, T/T

Supply Ability

5000tons per year

A500 Carbon Steel Square Tube High Strength Carbon Steel Structural Tubing For Building Structure

Get Best Price

video

AISI 4140 Seamless Tubing Medium Carbon Alloy Steel Seamless Pipe For Mechanical

Get Best Price

video

TP409 Ferritic Stainless Steel Seamless Tube For General Service

Get Best Price

video

ASME SA179 Seamless Carbon Steel Tubing Cold-Drawn Low-Carbon Steel Tube For Heat-Exchanger

Get Best Price

86-574-88086983

Contact Now

Product Description

Hydraulic Cylinder steel tubes and pipes EN10305-1 E355 St52 16Mn

Torich International Limited is a professional manufacturer and exporter of steel pipes materials. It is an international

marketing and sales company specialized in steel tubes, which holds the factories of Seamless Steel Tubes with

Carbon and Alloy Steel Grade, Welded Precision Steel Tubes,DOM Steel Tubes, Seamless & Welded Stainless

Steel Tubes with Nickel and Alloy Steel Grade. High precision steel tubes is our mainly products.

Standard : GB/T3639, GB/T8713, EN10305-1:2002, EN10305-2:2002,
ASTM A519-2006, ASTM A513-2007, GB/T1591-2008, GB/T17396-2009

Material: 20#, 45#, Q345B, Q345D, 25Mn, 27SiMn, E355

Hydraulic and pneumatic cylnder tube standard/size/tolerance

Working method	Tube ID (mm)	Length (m)	Straightness (mm/m)	Tolerance on ID	Tolerance on WT	ID Roughness (um)
Cold Draw	40-400	≤12m	0.2-0.5	/	±5%	≤1.6
Cold Rolled	40-150	≤12m	0.2-0.5	/	±5%	≤0.8
Cold Draw-Honed	40-400	≤8m	0.2-0.3	H8-H9	±5%	≤0.4
Cold Draw-Rolling	50-300	≤8m	0.2-0.3	H8-H9	±5%	≤0.4
Deep hole boring-Roing	250-400	≤8m	0.2-0.3	H8-H9	±8%	≤0.8
Deep hole boring-Honed Roing	250-400	≤8m	0.2-0.3	H8-H9	±8%	≤0.4

Mechancial property

Final supply condition Steel grade	Cold finished(hard)(BK)		(Cold drawn and stress-relieved(BK+S)
Final supply condition Steel grade	T.S bN/mm²	Elogation 5%	T.S bN/mm²	Y.S Bn/mm²	Elogation 5%	Hardness HB	Impact value(-20℃)J
20	≥550	≥8	≥520	≥400	≥15	170	/
45	≥680	≥5	≥630	≥520	≥12	190	/
Q345B	≥660	≥8	≥620	≥520	≥15	190	/
Q345D	≥660	≥8	≥620	≥520	≥15	190	≥27
25Mn	≥640	≥8	≥620	≥510	≥15	190	/
27SiMn	≥780	≥5	≥700	≥580	≥10	210	/
E355	≥700	≥8	≥650	≥580	≥15	195	≥27

Chemecal composition

Steel grade	C	Si	Mn	P	S	Cr	Ni	Cu	V
20	0.17-0.23	0.17-0.37	0.35-0.65	≤0.035	≤0.035	≤0.25	≤0.30	≤0.25	/
45	0.42-0.50	0.17-0.37	0.50-0.80	≤0.035	≤0.035	≤0.25	≤0.30	≤0.25	/
Q345B	≤0.20	≤0.50	≤0.17	≤0.035	≤0.035	≤0.30	≤0.50	≤0.30	≤0.15
Q345D	≤0.18	≤0.50	≤0.17	≤0.030	≤0.025	≤0.30	≤0.50	≤0.30	≤0.15
25Mn	0.24-0.32	1.10-1.40	1.10-1.40	≤0.035	≤0.035	≤0.30	≤0.30	≤0.20	/
27SiMn	0.22-0.29	0.17-0.37	0.70-1.0	≤0.035	≤0.035	≤0.25	≤0.30	≤0.25	/
E355	≤0.22	≤0.50	≤1.60	≤0.035	≤0.025	/	/	/	/

(Tolerance on ID) um

ID Size	(Tolerance on ID)um
	H7	H8	H9	H10
30	+21 0	+33 0	+52 0	+84 0
>30-50	+25 0	+39 0	+62 0	+100 0
>50-80	+30 0	+46 0	+74 0	+120 0
>80-120	+35 0	+54 0	+87 0	+140 0
>120-180	+40 0	+63 0	+100 0	+160 0
>180-250	+46 0	+72 0	+115 0	+185 0
>250-315	+52 0	+81 0	+140 0	+210 0
>315-400	+57 0	+89 0	+170 0	+230 0
