Seamless Cold-Drawn Tubing ASTM A179 Low Carbon Steel Heat - Exchanger Tubes
Description:
| Appilcations | Boilers , Superheaters , Heat - Exchangers , Condensers Ubend Tubes according to Customer request |
| Outside Diameter | 5 - 420mm |
| Wall Thickness | 0.5 - 50mm |
| Length | Max12000mm |
Steel Grade and Chemical Compositions:
| C | 0.06 - 0.18 |
| Mn | 0.27 - 0.63 |
| P | ≤ 0.035 |
| S | ≤ 0.035 |
Mechanical Properties:
| Tensile Strength | min ksi ( Mpa ) 47 ( 325 ) ) |
| Yield Point | min ksi ( Mpa ) 26 ( 180 ) |
| Elongation | ≥ 35 % |
| Hardness | ≤ 75 HRB |
Tolerance for OD and WT ( SA - 450 / SA - 450M ):
| ODin ( mm ) | + | - | WTin( mm ) | + | - |
| ＜1 " ( 25.4 ) | 0.10 | 0.10 | ≤ 1.1/2 “ (38.1) | 20% | 0 |
| 1'' ~ 1.1'' ( 38.1 ~ 50.8 ) | 0.15 | 0.15 | ＞ 1.1/2 ” (38.2) | 022% | 0 |
| > 1.1/2 ( 38.1 ~ 50.8 ) | 0.20 | 0.20 | | | |
| 2'' ~ < 2.1/2'' ( 50.8 ~ 63.3 ) | 0.25 | 0.25 | | | |
| 2.1/2'' ~ -3 ( 63.5 ~ 76.2 ) | 0.30 | 0.30 | | | |
| 3'' ~ < 4'' ( 76.2 ~ 101.6 ) | 0.38 | 0.38 | | | |
Characteristic:
Good concentricity High Precision
Good surface quality Stable quality
Good OD and ID tolerance Smooth Roughness
Company Information:
Torich International Co.,Ltd is a professional manufacturer and exporter of steel pipes materials. It is an international marketing and sales company specialized in steel tubes, which holds the factories of Seamless Steel Tubes with Carbon and Alloy Steel Grade, Welded Precision Steel Tubes,DOM Steel Tubes, Seamless & Welded Stainless Steel Tubes with Nickel and Alloy Steel Grade.
Our factory was established since 1997, with the name of Haiyan Sanxin Steel Pipe Co., Ltd. The factories’ technicians are of great engineering experience in steel pipe industry for more than 20 years, which are in great command of production technology for Cold Drawing and Cold Rolling. So we have strong technician team and manufacturing capability.
