ASTM A485 Cold Drawn Precision Steel Tubes / Steel Pipe For Automobiles
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO 9001:2008 , BV , ABS , CCS , DNV , GL ,PED
Model Number:
ASTM A485
Trading Properties
Minimum Order Quantity:
5MT
Price:
negotiable
Payment Terms:
L/C, T/T
Supply Ability:
15000MT/Month
Product Summary
ASTM A485 Cold Drawn Precision Steel Tubes / Pipe For Automobiles ASTM A485 Bearing high hardenability modifications of high-carbon bearing quality steel Tube Technical Standard : ASTM A485 Steel grade : Grade 1 Grade 2 Grade 3 Grade 4 100CrMnSi4–4 100CrMnSi6–4 100CrMnSi6–6 100CrMo7 100CrMo7–3 ...
Product Details
Highlight:
low carbon steel pipe
,steel mechanical tubing
Material:
Bearing Steel Tube
Steel Grade:
Grade 1 Grade 2 Grade 3 Grade 4 100CrMnSi4–4 100CrMnSi6–4 100CrMnSi6–6 100CrMo7 100CrMo7–3 100CrMo7–4 100CrMnMoSi8–4–6
O.D.:
5-500mm
W.T.:
0.5-50mm
Length:
Max12000mm
Place Of Origin:
China
Surface Treatment:
Hot Rolled, Annealed
Application:
Manufacture Of Antifriction Bearings
Product Description
ASTM A485 Cold Drawn Precision Steel Tubes / Pipe For Automobiles
ASTM A485 Bearing high hardenability modifications of high-carbon bearing quality steel Tube
Technical Standard : ASTM A485
Steel grade : Grade 1 Grade 2 Grade 3 Grade 4 100CrMnSi4–4 100CrMnSi6–4 100CrMnSi6–6
100CrMo7 100CrMo7–3 100CrMo7–4 100CrMnMoSi8–4–6
Application:manufacture of antifriction bearings. Ball Bearing, Roller Bearing, Bearing rings etc .
| Grade | C | Mn | P (max) | S (max) | Si | Cr | Ni (max) | Ti (max) | Cu (max) | Mo | O (max) | Al (max) |
| Grade 1 | 0.90–1.05 | 0.90– 1.20 | 0.025 | 0.015 | 0.45–0.75 | 0.90–1.20 | 0.25 | 0.0050 | 0.30 | 0.10 (max) | 0.0015 | 0.050 |
| Grade 2 | 0.85– 1.00 | 1.40– 1.70 | 0.025 | 0.015 | 0.50–0.80 | 1.40–1.80 | 0.25 | 0.0050 | 0.30 | 0.10 (max) | 0.0015 | 0.050 |
| Grade 3 | 0.95– 1.10 | 0.65– 0.90 | 0.025 | 0.015 | 0.15–0.35 | 1.10–1.50 | 0.25 | 0.0050 | 0.30 | 0.20-0.30 | 0.0015 | 0.050 |
| Grade 4 | 0.95– 1.10 | 1.05– 1.35 | 0.025 | 0.015 | 0.15–0.35 | 1.10–1.50 | 0.25 | 0.0050 | 0.30 | 0.45-0.60 | 0.0015 | 0.050 |
| 100CrMn Si4–4 | 0.93– 1.05 | 0.90– 1.20 | 0.025 | 0.015 | 0.45–0.75 | 0.90–1.20 | - | - | 0.30 | 0.10 (max) | 0.0015 | 0.050 |
| 100CrMn Si6–4 | 0.93– 1.05 | 1.00– 1.20 | 0.025 | 0.015 | 0.45–0.75 | 1.40–1.65 | - | - | 0.30 | 0.10 (max) | 0.0015 | 0.050 |
| 100CrMn Si6–6 | 0.93– 1.05 | 1.40– 1.70 | 0.025 | 0.015 | 0.45–0.75 | 1.40–1.65 | - | - | 0.30 | 0.10 (max) | 0.0015 | 0.050 |
| 100CrMo7 | 0.93– 1.05 | 0.25– 0.45 | 0.025 | 0.015 | 0.15–0.35 | 1.65–1.95 | - | - | 0.30 | 0.15-0.30 | 0.0015 | 0.050 |
| 100CrMo7–3 | 0.93– 1.05 | 0.60– 0.80 | 0.025 | 0.015 | 0.15–0.35 | 1.65–1.95 | - | - | 0.30 | 0.20-0.35 | 0.0015 | 0.050 |
| 100CrMo7–4 | 0.93– 1.05 | 0.60– 0.80 | 0.025 | 0.015 | 0.15–0.35 | 1.65–1.95 | - | - | 0.30 | 0.40-0.50 | 0.0015 | 0.050 |
| 100CrMnM oSi8–4–6 | 0.93– 1.05 | 0.80– 1.10 | 0.025 | 0.015 | 0.40–0.60 | 1.80–2.05 | - | - | 0.30 | 0.50-0.60 | 0.0015 | 0.050 |
