ASTM A519 1035 Seamless Carbon And Alloy Steel Mechanical Tubing For Hydraulic
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 1Ton | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | In bundles or in wooden boxes. | Delivery Time : | 20-40days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 60000 Ton/Tons per Year |
| Place of Origin: | ZheJiang/China | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO9001 ISO14001 TS16949 | Model Number: | GB/T 34105 |
|
Detail Information |
|||
| Standard: | GB | Grade: | S22053 |
|---|---|---|---|
| Application: | Ocean Engineering Structures | Section Shape: | Round |
| Alloy Or Not: | Is Alloy | Technique: | Hot Rolled |
| Surface Treatment: | Customerized | Secondary Or Not: | Non-secondary |
| Special Pipe: | Precision Seamless Pipe | Shape: | Round Shape |
| Product Name: | Seamless Steel Tube | Surface: | Customers't Requirement |
| High Light: | S22053 Stainless Steel Pipe,Ocean Engineering Structures Seamless Steel Tube,Hot Rolled Duplex Stainless Steel Pipe |
||
Product Description
The GB/T 34105 S22053 hot rolled duplex stainless steel pipe is made from a specific material composition. It is designed to provide excellent corrosion resistance and high strength, making it suitable for use in ocean engineering structures.
| Specification | Value |
|---|---|
| Standard | GB/T 34105 |
| Grade | S22053 |
| Manufacturing Method | Hot Rolled |
| Type | Duplex Stainless Steel Pipe |
| Application | Ocean Engineering Structures |
The GB/T 34105 S22053 hot rolled duplex stainless steel pipe offers several key features, which make it a preferred choice for ocean engineering structures:
The chemical composition of the GB/T 34105 S22053 hot rolled duplex stainless steel pipe is as follows:
| Element | Composition (Weight %) |
|---|---|
| Chromium (Cr) | 21.5 - 23.5 |
| Nickel (Ni) | 4.5 - 6.5 |
| Molybdenum (Mo) | 2.5 - 3.5 |
| Nitrogen (N) | 0.15 - 0.25 |
| Manganese (Mn) | ≤ 2.00 |
| Silicon (Si) | ≤ 1.00 |
| Copper (Cu) | 1.00 - 2.50 |
| Sulfur (S) | ≤ 0.020 |
| Phosphorus (P) | ≤ 0.035 |
The mechanical properties of the GB/T 34105 S22053 hot rolled duplex stainless steel pipe are as follows:
| Property | Value |
|---|---|
| Yield Strength (Rp0.2) | ≥ 450 MPa |
| Tensile Strength (Rm) | 650 - 850 MPa |
| Elongation (A) | ≥ 25% |
| Hardness (HBW) | ≤ 290 |
| Impact Energy (KV2/J) | ≥ 60 (Longitudinal) |
| ≥ 30 (Transverse) |
The GB/T 34105 S22053 hot rolled duplex stainless steel pipe falls under the S22053 steel grade. This steel grade is specifically designed to meet the requirements of ocean engineering structures while providing excellent corrosion resistance and high mechanical strength.
The GB/T 34105 S22053 hot rolled duplex stainless steel pipe is commonly used in various ocean engineering structures, including offshore platforms, underwater pipelines, and marine vessels. Its corrosion resistance, strength, and durability make it suitable for such applications, offering long-term protection in highly demanding marine environments.
In addition to the GB/T 34105 S22053, there are several alternative grades that can be considered for hot rolled duplex stainless steel pipes used in ocean engineering structures. Some potential alternatives include:
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
