DIN 2393 St37-2 Welded Steel Tube Precision Cold Drawn Welded Steel Pipe For Sleeve
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
Minimum Order Quantity : | 1Tons | Price : | Negotiable |
---|---|---|---|
Packaging Details : | in bundles or in wooden box | Delivery Time : | 4-8weeks |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 5000Tons per Year |
Place of Origin: | China,zhejiang | Brand Name: | TORICH |
---|---|---|---|
Certification: | ISO9001, ISO14001, TS16949 | Model Number: | GB/T 28413 SA178 |
Detail Information |
|||
Section Shape: | Round | Secondary Or Not: | Non-secondary |
---|---|---|---|
Application: | Boiler Heat Exchangers | Alloy Or Not: | Non-alloy |
Standard: | GB | Grade Group: | A53-A369 |
Product Name: | HFW Steel Pipes | ||
High Light: | SA178 Boiler Tube,High Frequency Welded Carbon Steel Pipes,GB/T 28413 Carbon Steel Pipes |
Product Description
GB/T 28413 SA178 is a standard specification for high-frequency welded carbon steel pipes commonly used in boiler heat exchangers. This article provides an overview of the material, specification, key features, chemical composition, mechanical properties, steel grades, applications, and possible alternative grades for SA178 pipes.
The material used for GB/T 28413 SA178 pipes is carbon steel. Carbon steel is an alloy of iron and carbon, with small amounts of other elements. It is widely used in various industries due to its excellent strength, weldability, and affordability.
The specification of GB/T 28413 SA178 pipes includes the following parameters:
Parameter | Specification |
---|---|
Outer Diameter | 10 mm to 168 mm |
Wall Thickness | 2 mm to 20 mm |
Length | 6 meters or as per customer's request |
The chemical composition of GB/T 28413 SA178 pipes typically includes the following elements:
Element | Percentage Range |
---|---|
Carbon | 0.06%-0.18% |
Manganese | 0.27%-0.63% |
Phosphorus | 0.035% maximum |
Sulfur | 0.035% maximum |
Silicon | 0.10% maximum |
The mechanical properties of GB/T 28413 SA178 pipes are as follows:
Property | Minimum Value |
---|---|
Tensile Strength | 325 MPa (min) |
Yield Strength | 180 MPa (min) |
Elongation | 35% (min) |
Hardness (Rockwell) | HRB 72 (max) for Grade A |
HRB 79 (max) for Grade C |
GB/T 28413 SA178 pipes are available in two steel grades: Grade A and Grade C. The steel grade determines the specific mechanical properties and suitability for different applications.
GB/T 28413 SA178 pipes find extensive usage in boiler heat exchangers, where they are used for conveying heated fluids. They are commonly employed in industrial settings such as power plants, chemical plants, and manufacturing facilities.
In addition to GB/T 28413 SA178, there are several alternative grades of carbon steel pipes available in the market. Some commonly used alternatives include ASTM A178 Grade A, ASTM A192, and DIN 17175 st35.8 pipes. These alternatives may have slightly different specifications and properties, so careful consideration is essential before selecting the appropriate grade for specific applications.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
