Precision Hydraulic Tubing EN10305-1 Seamless Cold Drawn Steel Tubes
Basic Properties
Place of Origin:
China
Brand Name:
TORICH
Certification:
ISO 9001-2008 ISO14001 TS16949 DNV
Model Number:
EN10305-1
Trading Properties
Minimum Order Quantity:
5 tons
Price:
900-1200USD/ton
Payment Terms:
L/C, D/A, D/P, T/T
Supply Ability:
50000 tons one year
Product Summary
Precision Hydraulic Tubing EN10305-1 Seamless Cold Drawn Steel Tubes Standard: EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes Carbon Steel Precision Tube for precision applications. Ra roughness max 0.8μm Applications: for Hydraulic Systems Size range for cold-drawn precision seamless steel tube: ...
Product Details
Highlight:
precision seamless pipe
,precision pipes and tubes
Material:
Carbon And Alloy Steel
Steel Grade:
E235 E355 Or Others
Shape:
Round
Standard:
EN 10305-1
Dimension:
OD6-380mm*WT-35mm*max12000mm
Manufacture:
Seamless Cold Drawn/Rolling
Applications:
For Hydraulic Systems
MTC:
EN10204 3.1B
Product Description
Precision Hydraulic Tubing EN10305-1 Seamless Cold Drawn Steel Tubes
Standard: EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes
Carbon Steel Precision Tube for precision applications.
Ra roughness max 0.8μm
Applications: for Hydraulic Systems
Size range for cold-drawn precision seamless steel tube:
O.D.:6-380mm
W.T.:1-35mm
L:max12000mm
Steel Grade and Chemical Compositions:
| Steel Grade | C | Si | Mn | P | S | Al | |
| Steel Name | Steel Number | max | max | max | max | max | min |
| E215 | 1.0212 | 0.10 | 0.05 | 0.70 | 0.025 | 0.025 | 0.025 |
| E235 | 1.0308 | 0.17 | 0.35 | 1.20 | 0.025 | 0.025 | - |
| E355 | 1.0580 | 0.22 | 0.55 | 1.60 | 0.025 | 0.025 | - |
| Mechanical properties at room temperature | |||||||||||||
| Steel grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Nubmer | (+Cc) | (+LCc) | (+SR) | (+Ad) | (+N) NBK | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290-430 | 215 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340-480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 | 450 | 22 | 490-630 | 355 | 22 |
Note: Special steel grade is also available, according to customer request.
Container Loading and Ready for Shipment
