EN 10305-2 34MnB5 ERW Welded Cold Drawn Precision steel Tubes For Automotive Industry
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 0.5 Ton | Price : | USD 1000-1500 Per Ton |
|---|---|---|---|
| Packaging Details : | In bundles | Delivery Time : | 4-6 Weeks |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 500 Tons Per Month |
| Place of Origin: | Zhejiang China | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO 9001 | Model Number: | DIN2391 |
|
Detail Information |
|||
| Sample: | Free | MOQ: | 500 Kg |
|---|---|---|---|
| Standard: | ASTM,DIN,GB,JIS,API | Grade: | 45#,20#,16Mn,10#,Q345 |
| Thickness: | 2 - 50 Mm,0.3-3.5mm,1 - 8 Mm | Technique: | Cold Drawn,Cold Rolled |
| Surface Treatment: | Galvanized,customerized,Copper Coated,Null,polished | Application: | Hydraulic Pipe,Construction,Fluid Pipe,Oil Pipe |
| Alloy Or Not: | Non-alloy | Section Shape: | Round |
| Type: | Welded Or Seamless Tube | Length: | 6M Or As Requirement,As Customer's Require |
| High Light: | API precision steel tubing,3.5mm thickness precision steel tube,0.3mm thickness precision steel tube |
||
Product Description
EN 10305-4 E235 (E255 E355 )+N Carbon Steel Pipe For Hydraulic And Pneumatic Systems
The surface of phosphating precision seamless steel pipe is especially suitable for painting or spray coating.
The paint surface has strong adhesion, excellent effect and beautiful ,anti rust effect Greatly strengthened.
|
Name
|
Scope mm | DIN seriesmm |
| OD | 04-30 | ±0.08 |
| OD | 31-40 | ±0.15 |
| OD | 41-50 | ±0.20 |
| OD | 51-60 | ±0.25 |
| Wall | 0.5-7 | ±10% |
Production Routing:
Quality carbon steel from bao steel etc big mill, cold drawing the heat treatment without oxidization , NBK condition. Do nondestructive testing ,
HT tests and do dipping oil antirust protection, Packed tube in wooden boxes.
Surface:
Galvanization/Galvanized/Zinc Coated
Blue White Zinc (Trivalent Chromium Passivation)
Plating Colour Zinc(Trivalent Chromium Passivation)
Yellow, Army-Green
Phosphated/Black Phosphated
Delivery Condition:
The tubes can be produced in the following delivery conditions:
NBK
After the final cold forming process the tubes are annealed above the upper transformation point in a controlled atmosphere
(+)N
After the final cold forming process the tubes are annealed above the upper transformation point in a controlled atmosphere
BK (+C)
Cold finished/hard (cold finished as drawn).
No heat treatment after the last cold forming process.
BKW (+LC)
Cold finished/soft (lightly cold worked)
After the last heat treatment there is a light finishing pass (cold drawing).
BKS (+SR)
Cold finished/stress relieve annealed.
After the final cold forming process the tubes are stress relieve annealed.
GBK (+A)
Annealed.
After the final cold forming process the tubes are annealed in a controlled atmosphere.
