ASTM A789 Super Duplex 2507 Pipe Cold Drawn Stainless Steel Tube For Petrochemical
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
Minimum Order Quantity : | 0.5 tons | Price : | negotiable |
---|---|---|---|
Packaging Details : | In bundles | Delivery Time : | 5-8 weeks days |
Payment Terms : | L/C, T/T | Supply Ability : | 5000tons per year |
Place of Origin: | China | Brand Name: | Torich |
---|---|---|---|
Certification: | ISO9001,ISO14001,TS16949 | Model Number: | ASME A789 |
Detail Information |
|||
Material: | Super Duplex 2507 | Standard: | ASME A789 |
---|---|---|---|
Surface: | Annealed & Pickled | Length: | 12000mm Max |
Delivery Time: | 30-40days | End: | Plain |
High Light: | Uns S31803 Stainless Steel Pipe,8 Inch Stainless Steel Pipe,S32750 Duplex Stainless Steel Pipe |
Product Description
Product Name: 8 Inch 80Sch Astm A789 Uns S31803 S32205, S32750 Duplex Stainless Steel Pipe Supplier
Standard: ASTM A789; ASTM A790; EN 10216-5 ect.
Material: S32205, S31803, S32304, S32750, 2205, 2507, etc.
UNS Designation | Specification |
S31803 | ASTM A789/SA789 |
S32205 | ASTM A789/SA789 |
S31500 | ASTM A789/SA789 |
S32550 | ASTM A789/SA789 |
S32750 | ASTM A789/SA789 |
S32950 | ASTM A789/SA789 |
S32520 | ASTM A789/SA789 |
UNS Designation |
Composition, % | ||||||||||
C Max |
Mn max |
P max |
S max |
Si max |
Ni | Cr | Mo | N | Cu | Others | |
S31803 | 0.03 | 2 | 0.03 | 0.02 | 1 | 4.5-6.5 | 21.0-23.0 | 2.5-3.5 | 0.08-0.20 | . . . | . . . |
S32205 | 0.03 | 2 | 0.03 | 0.02 | 1 | 4.5-6.5 | 22-23 | 3.0-3.5 | 0.14-0.20 | . . . | . . . |
S31500 | 0.03 | 1.20-2.00 | 0.03 | 0.03 | 1.40-2.0 | 4.3-5.2 | 18-19 | 2.5-3.0 | 0.05-0.10 | . . . | . . . |
S32550 | 0.04 | 1.5 | 0.04 | 0.03 | 1 | 4.5-6.5 | 24-27 | 2.9-3.9 | 0.10-0.25 | 1.50-2.50 | . . . |
S31200 | 0.03 | 2 | 0.045 | 0.03 | 1 | 5.5-6.5 | 24-26 | 1.-2.0 | 0.14-0.20 | . . . | . . . |
S31260 | 0.03 | 1 | 0.03 | 0.03 | 0.75 | 5.5-7.5 | 24-26 | 2.5-3.5 | 0.10-0.30 | 0.20-0.80 | W 0.10-0.50 |
S32001 | 0.03 | 4.0-6.0 | 0.04 | 0.03 | 1 | 1.0-3.0 | 19.5-21.5 | 0.6 | 0.05-0.17 | 1.00 max | . . . |
S32304 | 0.03 | 2.5 | 0.04 | 0.04 | 1 | 3.0-5.5 | 21.5-24.5 | 0.05-0.60 | 0.05-0.20 | 0.05-0.60 | . . . |
S32750 | 0.03 | 1.2 | 0.035 | 0.02 | 0.8 | 6.0-8.0 | 24-26 | 3.0-5.0 | 0.24-0.32 | 0.50max | . . . |
S32760 | 0.05 | 1 | 0.03 | 0.01 | 1 | 6.0-8.0 | 24-26 | 3.0-4.0 | 0.20-0.30 | 0.50-1.00 | W 0.50-1.00 |
S32950 | 0.03 | 2 | 0.035 | 0.01 | 0.6 | 3.5-5.2 | 26-29 | 1.0-2.5 | 0.15-0.35 | . . . | . . . |
S32520 | 0.03 | 1.5 | 0.035 | 0.02 | 0.8 | 5.5-8.0 | 23-25 | 3.0-5.0 | 0.20-0.35 | 0.8 | . . . |
Size Range:
Application: Downhole hydraulic control lines
Downhole chemical control lines
Subsea control lines for hydraulic power and chemical injection line
Flowline control
Instrumentation tubing
Smooth inner surface control line tubing used in fibre optic applications
Others
Item
|
material
|
size Length
|
Length(m)/pcs
|
Pressure(Mpa)
|
1
|
316L,304L,304
|
1/8″×0.025″
|
3200
|
80
|
2
|
316L,304L,304
|
1/8″×0.035″
|
3200
|
100
|
3
|
316L,304L,304
|
1/4″×0.035″
|
2000
|
100
|
4
|
316L,304L,304
|
1/4″×0.049″
|
2000
|
100
|
5
|
316L,304L,304
|
3/8″×0.035″
|
1500
|
80
|
6
|
316L,304L,304
|
3/8″×0.049″
|
1500
|
100
|
7
|
316L,304L,304
|
1/2″×0.049″
|
1000
|
80
|
8
|
316L,304L,304
|
1/2″×0.065″
|
1000
|
100
|
9
|
316L,304L,304
|
φ3mm×0.7mm
|
3200
|
80
|
10
|
316L,304L,304
|
φ3mm×0.9mm
|
3200
|
100
|
11
|
316L,304L,304
|
φ4mm×0.9mm
|
3000
|
100
|
12
|
316L,304L,304
|
φ4mm×1.1mm
|
3000
|
100
|
13
|
316L,304L,304
|
φ6mm×0.9mm
|
2000
|
100
|
14
|
316L,304L,304
|
φ6mm×1.1mm
|
2000
|
100
|
15
|
316L,304L,304
|
φ8mm×1mm
|
1800
|
80
|
16
|
316L,304L,304
|
φ8mm×1.2mm
|
1800
|
100
|
17
|
316L,304L,304
|
φ10mm×1mm
|
1500
|
70
|
18
|
316L,304L,304
|
φ10mm×1.2mm
|
1500
|
70
|
19
|
316L,304L,304
|
φ10mm×2mm
|
500
|
100
|
20
|
316L,304L,304
|
φ12mm×1.5mm
|
500
|
80
|
