ASTM A789 Super Duplex 2507 Pipe Cold Drawn Stainless Steel Tube For Petrochemical
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
Minimum Order Quantity : | 0.5 tons | Price : | negotiable |
---|---|---|---|
Packaging Details : | In bundles | Delivery Time : | 5-8 weeks days |
Payment Terms : | L/C, T/T | Supply Ability : | 5000tons per year |
Place of Origin: | China | Brand Name: | Torich |
---|---|---|---|
Certification: | ISO9001,ISO14001,TS16949 | Model Number: | ASME A789 |
Detail Information |
|||
Material: | Super Duplex 2507 | Standard: | ASME A789 |
---|---|---|---|
Surface: | Annealed & Pickled | Length: | 12000mm Max |
Delivery Time: | 30-40days | End: | Plain |
High Light: | Super Duplex 2507 Tubing,ISO Certified Stainless Steel Tube |
Product Description
Product Name: ISO certified manufacturer and supplier of ASTM A789 Seamless Super Duplex Alloy UNS S32750 2507 tubing
Standard: ASTM A789; ASTM A790; EN 10216-5 ect.
Material: S32205, S31803, S32304, S32750, 2205, 2507, etc.
2507 (UNS S32750) is a super duplex stainless steel designed for applications which require exceptional strength and corrosion resistance. 2507 is a 25% chromium, 4% molybdenum, and 7% nickel alloy resulting in excellent resistance to chloride pitting and crevice corrosion attack. The duplex structure provides 2507 with exceptional resistance to pitting and chloride stress corrosion cracking.
Usage of 2507 should be limited to applications below 600° F (316° C). Extended exposure to elevated temperatures can reduce its toughness and corrosion resistance.
UNS Designation | Specification |
S31803 | ASTM A789/SA789 |
S32205 | ASTM A789/SA789 |
S31500 | ASTM A789/SA789 |
S32550 | ASTM A789/SA789 |
S32750 | ASTM A789/SA789 |
S32950 | ASTM A789/SA789 |
S32520 | ASTM A789/SA789 |
UNS Designation |
Composition, % | ||||||||||
C Max |
Mn max |
P max |
S max |
Si max |
Ni | Cr | Mo | N | Cu | Others | |
S31803 | 0.03 | 2 | 0.03 | 0.02 | 1 | 4.5-6.5 | 21.0-23.0 | 2.5-3.5 | 0.08-0.20 | . . . | . . . |
S32205 | 0.03 | 2 | 0.03 | 0.02 | 1 | 4.5-6.5 | 22-23 | 3.0-3.5 | 0.14-0.20 | . . . | . . . |
S31500 | 0.03 | 1.20-2.00 | 0.03 | 0.03 | 1.40-2.0 | 4.3-5.2 | 18-19 | 2.5-3.0 | 0.05-0.10 | . . . | . . . |
S32550 | 0.04 | 1.5 | 0.04 | 0.03 | 1 | 4.5-6.5 | 24-27 | 2.9-3.9 | 0.10-0.25 | 1.50-2.50 | . . . |
S31200 | 0.03 | 2 | 0.045 | 0.03 | 1 | 5.5-6.5 | 24-26 | 1.-2.0 | 0.14-0.20 | . . . | . . . |
S31260 | 0.03 | 1 | 0.03 | 0.03 | 0.75 | 5.5-7.5 | 24-26 | 2.5-3.5 | 0.10-0.30 | 0.20-0.80 | W 0.10-0.50 |
S32001 | 0.03 | 4.0-6.0 | 0.04 | 0.03 | 1 | 1.0-3.0 | 19.5-21.5 | 0.6 | 0.05-0.17 | 1.00 max | . . . |
S32304 | 0.03 | 2.5 | 0.04 | 0.04 | 1 | 3.0-5.5 | 21.5-24.5 | 0.05-0.60 | 0.05-0.20 | 0.05-0.60 | . . . |
S32750 | 0.03 | 1.2 | 0.035 | 0.02 | 0.8 | 6.0-8.0 | 24-26 | 3.0-5.0 | 0.24-0.32 | 0.50max | . . . |
S32760 | 0.05 | 1 | 0.03 | 0.01 | 1 | 6.0-8.0 | 24-26 | 3.0-4.0 | 0.20-0.30 | 0.50-1.00 | W 0.50-1.00 |
S32950 | 0.03 | 2 | 0.035 | 0.01 | 0.6 | 3.5-5.2 | 26-29 | 1.0-2.5 | 0.15-0.35 | . . . | . . . |
S32520 | 0.03 | 1.5 | 0.035 | 0.02 | 0.8 | 5.5-8.0 | 23-25 | 3.0-5.0 | 0.20-0.35 | 0.8 | . . . |
Size Range:
Application: Downhole hydraulic control lines
Downhole chemical control lines
Subsea control lines for hydraulic power and chemical injection line
Flowline control
Instrumentation tubing
Smooth inner surface control line tubing used in fibre optic applications
Others
Item
|
material
|
size Length
|
Length(m)/pcs
|
Pressure(Mpa)
|
1
|
316L,304L,304
|
1/8″×0.025″
|
3200
|
80
|
2
|
316L,304L,304
|
1/8″×0.035″
|
3200
|
100
|
3
|
316L,304L,304
|
1/4″×0.035″
|
2000
|
100
|
4
|
316L,304L,304
|
1/4″×0.049″
|
2000
|
100
|
5
|
316L,304L,304
|
3/8″×0.035″
|
1500
|
80
|
6
|
316L,304L,304
|
3/8″×0.049″
|
1500
|
100
|
7
|
316L,304L,304
|
1/2″×0.049″
|
1000
|
80
|
8
|
316L,304L,304
|
1/2″×0.065″
|
1000
|
100
|
9
|
316L,304L,304
|
φ3mm×0.7mm
|
3200
|
80
|
10
|
316L,304L,304
|
φ3mm×0.9mm
|
3200
|
100
|
11
|
316L,304L,304
|
φ4mm×0.9mm
|
3000
|
100
|
12
|
316L,304L,304
|
φ4mm×1.1mm
|
3000
|
100
|
13
|
316L,304L,304
|
φ6mm×0.9mm
|
2000
|
100
|
14
|
316L,304L,304
|
φ6mm×1.1mm
|
2000
|
100
|
15
|
316L,304L,304
|
φ8mm×1mm
|
1800
|
80
|
16
|
316L,304L,304
|
φ8mm×1.2mm
|
1800
|
100
|
17
|
316L,304L,304
|
φ10mm×1mm
|
1500
|
70
|
18
|
316L,304L,304
|
φ10mm×1.2mm
|
1500
|
70
|
19
|
316L,304L,304
|
φ10mm×2mm
|
500
|
100
|
20
|
316L,304L,304
|
φ12mm×1.5mm
|
500
|
80
|
