ISO9001 Certified N06625 Inconel 625 Exhaust Tubing

Minimum Order Quantity : 100 Kg Price : Negotiable
Packaging Details : Suitable for product packaging Delivery Time : 3-4 Weeks
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 250 Tons Per Month
Place of Origin: Zhejiang China Brand Name: TORICH
Certification: ISO 9001 Model Number: Inconel 625

Detail Information

Resistance (μΩ.m): 1.5 Ultimate Strength (≥ MPa): 965
Powder Or Not: Not Powder Elongation (≥ %): 25
MOQ: 100Kg Material: Nickel Alloy
High Light:

ISO9001 Inconel 625 Exhaust Tubing

,

N06625 Inconel 625 Exhaust Tubing

,

N06625 inconel 625 seamless pipe

Product Description

Inconel 625 Tubes Sans Soudure for Heat Exchanger



Nickel and Nickel alloy referred to the alloy’s main elemental contents of Ni, Cu, Cr, Fe and Mo.

Those all characterized by its combination performance of high corrosion resistance and heat ability at temperature 650 ~ 1000 °C.

According to main alloy elements content can divide:

Ni –Cr – Mo alloy (Inconel 600 Series)

Ni-Cr-Fe alloy (Incoloy 800 Series)

Ni - Mo – Ni – Cu – (Hastelloy Series)

Pure Nickel and low alloy nickel (Nickel 200/201)



1.Introduction

Inconel Alloy 625 (UNS designation N06625) is a Ni-Cr based superalloy that possesses

high strength properties and resistance to elevated temperatures.as well as being able to

resist corrosion while being exposed to highly acidic environments makes it a fitting

choice for nuclear and marine applications.



2.Chemistry

  Cr Mo Co Nb+Ta Al Ti C Fe Mn Si P S Ni
Min 20 8 -- 3.15 -- -- -- -- -- -- -- -- Balance
Max 23 10 1 4.15 .4 .4 .1 5 .5 .5 .015 .015 Balance





3.ASTM (American Society for Testing and Materials) for various products made

  Tube Welded Sheet/Plate Bar Forging Fitting Wire
B444 B705 B444 B704 B443 B446



B444 Standard Specification for Nickel-Chromium-Molybdenum-Columbium Alloys(UNS N06625 and UNS N06852)

and Nickel-Chromium-Molybdenum-Silicon Alloy(UNS N06219)Pipe and Tube



Referenced ASTM Standard:
E829 Specification for general requirements for Nickel and Nickel alloy seamless pipe and tube.
E112 Test Methods for determining the average grain size.
G28 Test methods for detecting susceptibility to intergranular corrosion in wrought, Nickel-Rich, Chromium-Bearing Alloys.
G48 Test methods for piting and crevice corrosion resistance of stainless steel and related alloys by use of ferric chloride solution.



Keywords: Seamless pipe; seamless tube; N06219; N06625



Application:

- High temperature process

- Chemical and Petrochemical field

- Food field

- Power plants



Material List:

Incoloy 800, Incoloy 800H, Incoloy 825, Inconel 600, Hastelloy B, Hastelloy B2, Hastelloy C, Hastelloy C276,

Hastelloy C4, Hastelloy C22, Inconel 625, Inconel 718, Monel 400, Nickel 200



ISO9001 Certified  N06625 Inconel 625 Exhaust Tubing 0



ISO9001 Certified  N06625 Inconel 625 Exhaust Tubing 1



ISO9001 Certified  N06625 Inconel 625 Exhaust Tubing 2



FAQ:



Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to
quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
