Length 12000mm Oiled Surface En10305-2 Precision Steel Tube

China Length 12000mm Oiled Surface En10305-2 Precision Steel Tube supplier
Length 12000mm Oiled Surface En10305-2 Precision Steel Tube supplier Length 12000mm Oiled Surface En10305-2 Precision Steel Tube supplier Length 12000mm Oiled Surface En10305-2 Precision Steel Tube supplier

Large Image :  Length 12000mm Oiled Surface En10305-2 Precision Steel Tube

Product Details:

Place of Origin: Zhejiang China
Brand Name: TORICH
Certification: ISO 9001
Model Number: En10305-2

Payment & Shipping Terms:

Minimum Order Quantity: 1 Ton
Price: USD 850-950 Per Ton
Packaging Details: In bundles
Delivery Time: 4-6 Weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 Tons Per Month
Contact Now
Detailed Product Description
Thickness: 0.5 - 50 Mm Outer Diameter: 5 - 420 Mm
Length: Max 12000mm Application: Auto Industry,machinery Use
Delivery Time: 30-45 Days Surface Treatment: Oiled
High Light:

En10305-2 Precision Steel Tube

,

Oiled Surface Precision Steel Tube

,

E355 Seamless Steel Pipe

EN10305-2 Welded Steel Tubes with Precision Cold Drawn Steel Tubes for Mechanical / Automotive Application





Applications: for Auto industry/for Machinery use/Oil Cylinder Tube/Motorcyle Shock Absorber, inner cylinder/Telescopic Cylinders



Quick Detail:
Size Range: O.D.:5-420mm W.T.:0.5-50mm L:max12000mm

Steel Grade: E195,E215, E235, E275, E355,



Description:

ERW+ DOM

The tubes are manufactured from electric welded pre-tubes by cold drawing or other suitable processes.

The tubes not include welds used for joining lengths of flat rolled strips prior to forming the pre-tube



Description:

Mechanical tubing made from hot or cold-rolled steel.

Covers electric-resistance-welded low carbon steel tubing for use as mechanical tubing



Advantage:

Good concentricity, Better price than seamless.



Steel Grade and Chemical Compositions

Steel Grade C Si Mn P S
Steel Name Steel Number max max max max max
E155 1.0033 0.11 0.35 0.70 0.025 0.025
E195 1.0034 0.15 0.35 0.70 0.025 0.025
E235 1.0308 0.17 0.35 1.20 0.025 0.025
E275 1.0225 0.21 0.35 1.40 0.025 0.025
E355 1.0580 0.22 0.35 1.60 0.025 0.025



Mechanical properties at room temperature
Steel Grade Minimum values for the delivery condition a b
Steel Name (+Cc) (+LCc) (+SR) (+Ad) (+N)

Rm

Mpa

A %

Rm

Mpa

A %

Rm

Mpa

ReH

Mpa

A %

Rm

Mpa

A %

Rm

Mpa

ReHe

Mpa

A %
E155 1.0033 400 6 350 10 350 245 18 260 28 270-410 155 28
E195 1.0034 420 6 370 10 370 260 18 290 28 300-440 195 28
E235 1.0308 490 6 440 10 440 325 14 315 25 340-480 235 25
E275 1.0225 560 5 510 8 510 375 12 390 21 410-550 275 21
E355 1.0580 640 4 590 6 590 435 10 450 22 490-630 355 22



aRm: tensile strength; ReH: upper yield strength; A: elongation after fracture
b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm
d For calculation purposes the following relation is recommended:ReH≥0.5Rm
e For tubes with outside diameter ≤30mm and wall thickness ≤3mm the ReH minimim values are 10Mpa lower than the values given in this Table
Note: Special steel grade is also available, according to customer request.



Applications:

Auto industry/for Machinery use/Oil Cylinder Tube/Motorcycle Shock Absorber

inner cylinder/Telescopic Cylinders



Competitive Advantage:

Good source of raw material from Bao Steel.

Prompt delivery time according to PO and agreement.

Produce exactly according to standard and customer's requirement.

Experienced export team for customer service, quick reply within 24 hours.
