EN 10305-3 E195 ERW Welded Cold Sized Carbon Steel Tube For Precision Applications
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 1 Ton | Packaging Details : | 1.Wrapped in waterproof paper of steel pipe tube. 2.Sackcloth with several steel strips of steel tube pipe. 3.Cover cap of steel pipe tube. 4. Wooden case of steel pipe tube. |
|---|---|---|---|
| Delivery Time : | 4-6 Weeks | Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 500 Ton Per Month |
| Place of Origin: | Zhejiang China | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO 9001 | Model Number: | DIN 2391 |
|
Detail Information |
|||
| Load Type: | Gas | Usage: | Automobile;Auto;Car |
|---|---|---|---|
| Color Of Of Steel Pipe Tube: | Slivery Of Steel Pipe Tube | Craft Of Steel Pipe Tube: | Sold Drawn & Cold Rolled |
| Certification: | ISO 9001 | Name: | Carbon Steel Seamless Pipe |
| High Light: | precision steel pipe,precision seamless pipe |
||
Product Description
DIN2391 Carbon Seamless Steel Pipe Tube
German Standard:
Chemical Composition
|
Standard
|
Steel Grade
|
C(%) | Si(%) | Mn(%) | S(%) | P(%) |
| DIN 2391 | St35 | ≤0.17 | ≤0.35 | ≥0.40 | ≤0.025 | ≤0.025 |
| St37 | ≤0.17 | ≤0.35 | ≥0.40 | ≤0.025 | ≤0.025 | |
| St37.4 | ≤0.17 | ≤0.35 | ≥0.40 | ≤0.025 | ≤0.025 | |
| St45 | ≤0.21 | ≤0.35 | ≥0.40 | ≤0.025 | ≤0.025 | |
| St44 | ≤0.21 | ≤0.35 | ≥0.40 | ≤0.025 | ≤0.025 | |
| St52 | ≤0.22 | ≤0.35 | ≥1.60 | ≤0.025 |
≤0.025 |
Mechanical Property:
| Standard | Steel Grade | Mechanical Performance | ||||
| GBK(+A) | NBK(+N) | |||||
|
Tensile Strength (Rm mpa) |
Elongation rate (A5 %) |
Tensile Strength (Rm mpa) |
Yield Strength (Reh mpa) |
Elongation rate (A5 %) |
||
| DIN 2391 | St35 | ≥315 | ≥25 | 346-478 | ≥235 | ≥25 |
| St37 | ≥315 | ≥25 | 346-478 | ≥235 | ≥25 | |
| St37.4 | ≥315 | ≥25 | 346-478 | ≥235 | ≥25 | |
| St45 | ≥390 | ≥21 | 440-570 | ≥255 | ≥21 | |
| St44 | ≥390 | ≥21 | 440-570 | ≥255 | ≥21 | |
| St52 | ≥490 | ≥22 | 490-630 | ≥355 | ≥22 | |
Other Specification:
| End Shape |
Beveled end, plain end, vanished, or adding plastic caps to protect the two ends as per customer's requirements |
|
|
Surface Treatment |
Oiled, Galvanized, Phosphate etc | |
| Technique | Cold drawn & cold rolled | |
| Application | 1. Automotive and mechanical pipes | |
| 2. Petroleum cracking pipes | ||
| 3. High Pressure Boiler Pipe | ||
| 4. Low and middle pressure fluid transportation pipeline | ||
| 5. Chemical fertilizer equipment pipes | ||
| 6. Heat exchanger pipes | ||
|
Delivery Conditions |
1. BK (+C) | No heat treatment after last cold forming process. |
| 2. BKW (+LC) | After last heat treatment there is a light finishing pass (cold drawing) | |
| 3. BKS (+SR) | After the final cold forming process the tubes are stress relieve annealed. | |
| 4. GBK (+A) | After the final cold forming process the tubes are annealed in a controlled atmosphere. | |
| 5. NBK (+N) |
After the final cold forming process the tubes are annealed above the upper transformation point in a controlled atmosphere. |
|
| Package | 1. Bundle Packing. | |
| 2. Plain end or vanished as per customer's request. | ||
| 3. Wrapped in waterproof paper. | ||
| 4. Sackcloth with several steel strips. | ||
| 5. Pack in heavy tri-wall boxes. | ||
