Cold Drawn Seamless Steel Tube for Mechanical Applications
Basic Properties
Place of Origin:
Zhejiang,China
Brand Name:
TORICH
Certification:
ISO9001,ISO14001,TS16949
Model Number:
ASTM A519
Trading Properties
Minimum Order Quantity:
5 TONS
Price:
Negotiable
Payment Terms:
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:
50000 TONS PER YEAR
Product Summary
Precision Cold Drawn Seamless Steel Tube Used for Mechanical Purpose Standard: ASTM A519, Seamless circular steel tubes for mechanical and general engineering purposes - Technical delivery conditions Non-alloy and alloy steel tubes Application: for seamless circular tubes made of non-alloy and alloy ...
Product Details
Highlight:
cold drawn steel tube
,cold drawn tubes
Product Name:
Precision Cold Drawn Seamless Steel Tube Used For Mechanical Purpose
Keyword:
Cold Drawn Seamless Steel Tube
Material:
1008,1010,1020,1026,1045,4130,4140, E235, E275, E315, E355, E470 C15, C22, 38Mn6, 41Cr4, 25CrMo4, 30CrMo4, 34CrMo4, 42CrMo4
Shape:
Round
Application:
For Seamless Circular Tubes Made Of Non-alloy And Alloy Steels For Mechanical And General Engineering Purposes.
Delivery Condition:
BK,BKW,BKS,GBK,NBK
OD:
5-420mm
WT:
0.5-50mm
Length:
Max12000mm
Brand:
TORICH
Product Description
Precision Cold Drawn Seamless Steel Tube Used for Mechanical Purpose
Standard: ASTM A519, Seamless circular steel tubes for mechanical and general engineering purposes
- Technical delivery conditions Non-alloy and alloy steel tubes
Application: for seamless circular tubes made of non-alloy and alloy steels for mechanical and gneral engineering purposes.
Size range: O.D.: 5-420mm W.T.: 0.5-50mm L:max12000mm
Material:
1008,1010,1020,1026,1045,4130,4140,
E235, E275, E315, E355, E470
C15, C22, 38Mn6, 41Cr4,
25CrMo4, 30CrMo4, 34CrMo4, 42CrMo4
Delivery condition:
Normalizin rolling process or normalized by heat treatment in a furnance.
Manufacture:
The tubes are manufactured by Seamless Cold Drawn or Seamless Cold Rolling.
| Steel Grade | C | Si | Mn | P | |||
| Steel Number | max | max | max | max | |||
| 1.0308 | 0.17 | 0.35 | 1.20 | 0.035 | |||
| 1.0225 | 0.21 | 0.35 | 1.40 | 0.035 | |||
| 1.0236 | 0.21 | 0.30 | 1.50 | 0.035 | |||
| 1.0580 | 0.22 | 0.55 | 1.60 | 0.035 | |||
| 1.0536 | 0.16-0.22 | 0.10-0.50 | 1.3-1.70 | 0.035 | |||
